Page 1096​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

>DistanceSourcetoDetector​

(0018,1110)​

1C​

Distancefromsourcetoreceptorplaneperpendiculartothereceptor​







plane in mm or distance in mm from source to detector center on​







the chest wall line. See Section C.8.11.7.1.1.​







Required if present and consistent in the contributing SOP​







Instances.​







Note​







This value is traditionally referred to as Source Image​







Receptor Distance (SID).​

>Distance Source to​

(0018,9402)​

1C​

Distance from source to isocenter in mm.​

Isocenter​





Required if present and consistent in the contributing SOP​













Instances.​

>Focal Spot(s)​

(0018,1190)​

1C​

Nominal focal spot size in mm used to acquire this image.​







Required if present and consistent in the contributing SOP​







Instances.​

>Filter Type​

(0018,1160)​

1C​

Type of filter(s) inserted into the X-Ray beam (e.g., wedges). See​







Attribute Description in Section C.8.7.10 for Defined Terms.​







Note​







Multipletypeoffilterscanbeexpressedbyacombination,​







e.g., BUTTERFLY+WEDGE.​







Required if present and consistent in the contributing SOP​







Instances.​

>Filter Material​

(0018,7050)​

1C​

The X-Ray absorbing material used in the filter. May be​







multi-valued. See Attribute Description in Section C.8.7.10 for​







Defined Terms.​







Required if present and consistent in the contributing SOP​







Instances.​

>Filter Thickness Minimum​

(0018,7052)​

1C​

See Attribute Description in Section C.8.7.10.​







Required if present and consistent in the contributing SOP​







Instances.​

>Filter Thickness Maximum​

(0018,7054)​

1C​

See Attribute Description in Section C.8.7.10.​







Required if present and consistent in the contributing SOP​







Instances.​

>Filter Beam Path Length​

(0018,7056)​

1C​

See Attribute Description in Section C.8.7.10.​

Minimum​





Required if present and consistent in the contributing SOP​













Instances.​

>Filter Beam Path Length​

(0018,7058)​

1C​

See Attribute Description in Section C.8.7.10.​

Maximum​





Required if present and consistent in the contributing SOP​













Instances.​

>Table X Position to​

(0018,9466)​

3​

XpositionoftheTableReferencePointwithrespecttotheIsocenter​

Isocenter​





(mm).​

See Section C.8.19.6.13.1.3 for further explanation.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 1097​

Attribute Name​

Tag​

Type​

Attribute Description​



>Table Y Position to​

(0018,9467)​

3​

YpositionoftheTableReferencePointwithrespecttotheIsocenter​

Isocenter​





(mm).​









See Section C.8.19.6.13.1.3 for further explanation.​



>Table Z Position to​

(0018,9468)​

3​

ZpositionoftheTableReferencePointwithrespecttotheIsocenter​

Isocenter​





(mm).​









See Section C.8.19.6.13.1.3 for further explanation.​



>Table Horizontal Rotation​

(0018,9469)​

3​

Rotation of the table in the horizontal plane.​



Angle​





See Section C.8.19.6.13.1.3 for further explanation.​











>Table Head Tilt Angle​

(0018,9470)​

3​

Angle of the head-feet axis of the table in degrees relative to the​







horizontal plane.​









See Section C.8.19.6.13.1.3 for further explanation.​



>Table Cradle Tilt Angle​

(0018,9471)​

3​

Angle of the left-right axis of the table in degrees relative to the​







horizontal plane.​









See Section C.8.19.6.13.1.3 for further explanation.​



>Include Table C.8.21.3.1.3-1 “X-Ray 3D General Positioner​





Movement Macro Attributes”​









>Per Projection Acquisition​

(0018,9538)​

1C​

Sequencecontainingdetailedacquisitioncontextofeachindividual​

Sequence​





projection used in this acquisition context.​









One or more Items shall be included in this Sequence.​







Required if present and consistent in the contributing SOP​







Instances.​



>>IncludeTableC.8.21.3.1.2-1“X-Ray3DGeneralPerProjection​



Acquisition Macro Attributes”​









>>Positioner Isocenter​

(0018,9463)​

1C​

PositionoftheX-Raycenterbeamforthisprojectionintheisocenter​

Primary Angle​





reference system in the X direction (deg).​









See Section C.8.19.6.13.1.2 for further explanation.​









Required if present and consistent in the contributing SOP​







Instances.​



>>Positioner Isocenter​

(0018,9464)​

1C​

PositionoftheX-Raycenterbeamforthisprojectionintheisocenter​

Secondary Angle​





reference system in the Z direction (deg).​









See Section C.8.19.6.13.1.2 for further explanation.​









Required if present and consistent in the contributing SOP​







Instances.​



>>Positioner Isocenter​

(0018,9465)​

1C​

Rotation of the X-Ray detector plane for this projection (deg).​

Detector Rotation Angle​





See Section C.8.19.6.13.1.2 for further explanation.​

















Required if present and consistent in the contributing SOP​







Instances.​



>>Positioner Primary Angle​

(0018,1510)​

3​

Position of the X-Ray Image Intensifier about the patient from the​







RAO to LAO direction where movement from RAO to vertical is​







positive.​



See Section C.8.7.5.1.2 for further explanation.​

- Standard -​

Page 1098​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

>>Positioner Secondary​

(0018,1511)​

3​

Position of the X-Ray Image Intensifier about the patient from the​

Angle​





CAU to CRA direction where movement from CAU to vertical is​







positive.​

See Section C.8.7.5.1.2 for further explanation.​

C.8.21.3.3 X-Ray 3D Craniofacial Acquisition Module​

This section describes the X-Ray 3D Craniofacial Acquisition Module.​

Table C.8.21.3.3-1. X-Ray 3D Craniofacial Acquisition Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

X-Ray 3D Acquisition​

(0018,9507)​

1​

Each Item represents a acquisition context related to a​

Sequence​





set of frames of SOP Instance defined by this IOD,​







The values of Acquisition Index (0020,9518) may be used​







as index to Items in this Sequence.​







One or more Items shall be included in this Sequence.​

>Field of View Shape​

(0018,1147)​

1C​

Shape of the Field of View in the referenced images.​







Enumerated Values:​







RECTANGLE​







ROUND​







HEXAGONAL​







RequiredifpresentandconsistentinthecontributingSOP​







Instances.​

>X-Ray Receptor Type​

(0018,9420)​

1C​

Identifies the type of X-Ray receptor used.​







Enumerated Values:​







DIGITAL_DETECTOR​







RequiredifpresentandconsistentinthecontributingSOP​







Instances.​

>Include Table C.8.21.3.1.1-1 “X-Ray 3D General Shared Acquisition​



Macro Attributes”​







>Include Table C.8-71b “Digital X-Ray Detector Macro Attributes”​



>Per Projection Acquisition​

(0018,9538)​

1C​

Sequence containing detailed acquisition context of each​

Sequence​





individual projection used in this acquisition context.​

One or more Items shall be included in this Sequence.​

RequiredifpresentandconsistentinthecontributingSOP​

Instances.​

>>Include Table C.8.21.3.1.2-1 “X-Ray 3D General Per Projection​ Acquisition Macro Attributes”​

C.8.21.3.4 Breast Tomosynthesis Acquisition Module​

This section describes the Breast Tomosynthesis Acquisition Module.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​ Page 1099​

Table C.8.21.3.4-1. Breast Tomosynthesis Acquisition Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

X-Ray 3D Acquisition​

(0018,9507)​

1​ Each Item represents an acquisition context related to one or more​

Sequence​





reconstructions.​







The values of Acquisition Index (0020,9518) may be used as index in​







this Sequence.​







One or more Items shall be included in this Sequence.​

>Field of View Shape​

(0018,1147)​

1​ Shape of the Field of View in the source projection images.​







Enumerated Values:​







RECTANGLE​

>X-Ray Receptor Type​

(0018,9420)​

1​ Identifies the type of X-Ray receptor used.​

Enumerated Values:​

DIGITAL_DETECTOR​

>Include Table C.8.21.3.1.1-1 “X-Ray 3D General Shared​

Acquisition Macro Attributes”​

>Include Table C.8.21.3.1.3-1 “X-Ray 3D General Positioner​

Movement Macro Attributes”​

>Distance Source to​

(0018,1110)​

1​ Distance in mm from source to detector center on the chest wall line.​

Detector​



Note​









1.​This value is traditionally referred to as Source Image​





Distance (SID).​





2.​See Section C.8.11.7.1.1.​

>DistanceSourcetoPatient​

(0018,1111)​

1​ Distance in mm from source to the breast support side that is closest​





to the Imaging Subject, as measured along the X-Ray beam vector.​





Note​





1.​This value is traditionally referred to as Source Object​





Distance (SOD).​





2.​See notes for this Attribute in Section C.8.11.5 DX​





Positioning Module.​





3.​See Section C.8.11.7.1.1 for description of X-Ray beam​





vector.​

>Estimated Radiographic​

(0018,1114)​

1​ Ratio of Source Image Receptor Distance (SID) over Source Object​

Magnification Factor​



Distance (SOD).​

>Anode Target Material​

(0018,1191)​

1​ The primary material in the anode of the X-Ray source.​





Defined Terms:​





TUNGSTEN​





MOLYBDENUM​





RHODIUM​

>Body Part Thickness​

(0018,11A0)​

1​ The average thickness in mm of the body part examined when​





compressed, if compression has been applied during exposure.​

- Standard -​

Page 1100​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

>Exposure Control Mode​

(0018,7060)​

1​ Type of exposure control.​







Defined Terms:​







MANUAL​







AUTOMATIC​

>Exposure Control Mode​

(0018,7062)​

1​ Text description of the mechanism of exposure control.​

Description​





May describe the number and type of exposure sensors or position​













of the sensitive area of the imaging detector.​

>Half Value Layer​

(0040,0314)​

1​ ThethicknessofAluminuminmmrequiredtoreducetheX-RayOutput​







(0040,0312) by a factor of two.​







Note​







This value may be a calibrated value rather than measured​







during the exposure.​

>Organ Dose​

(0040,0316)​

3​ Organ dose value measured in dGy representing the collective total​







for all acquired frames described in this Sequence Item.​







Note​







This may be an estimated value.​

>Entrance Dose in mGy​

(0040,8302)​

3​ Entrance dose value measured in mGy at the surface of the patient​







representing the collective total for all acquired frames described in​







this Sequence Item.​







Note​







Thismaybeanestimatedvaluebasedonassumptionsabout​







the patient's body size and habitus.​

>Entrance Dose Derivation​

(0040,8303)​

3​ Describes what type of dose is represented by the values of Entrance​







Dose in mGy (0040,8302).​







Enumerated Values:​







IAK​

Represents air kerma at the entrance surface, no​









backscatter included, no air kerma to tissue dose​









conversion applied.​







ESAK​

Represents air kerma at the entrance surface, with​









backscatter included, no air kerma to tissue dose​









conversion applied.​







ESDBS​

Represents absorbed dose in tissue at the entrance​









surface, with backscatter included.​







ESDNOBS​Represents absorbed dose in tissue at the entrance​









surface, without backscatter included.​







Only meaningful if Entrance Dose in mGy (0040,8302) is present.​

>Focal Spot(s)​

(0018,1190)​

1​

Nominal focal spot size in mm used to acquire the projection images.​

>Detector Binning​

(0018,701A)​

1C​

Number of active detectors used to generate a single pixel. Specified​







as number of row detectors per pixel then column.​







Required if detector binning was applied to the projection images.​

>Detector Temperature​

(0018,7001)​

1​

Detector temperature during exposure in degrees Celsius.​

>Filter Type​

(0018,1160)​

1​

Type of filter(s) inserted into the X-Ray beam (e.g., wedges). See​







Attribute Description in Section C.8.7.10 for Defined Terms.​

- Standard -​

Смотрите также:

«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
Значение, сущность и содержание социально — педагогической деятельности в организации для детей-сирот и детей, оставшихся без попечения родителей
__RGR2
__RGR2
_11_А. Франс для эл версии
_индив анализ данных
- Интерфейс 485 и оптопорт 11
:Конвергентный подход к проектированию дополнительных общеобразовательных общеразвивающих программ
