DICOM PS3.3 2020a - Information Object Definitions​

Page 1051​

BIPLANE​ Image is part of a Bi-plane acquisition​

UNDEFINED​ Image is created by using data from one or two planes (e.g., reconstructed projection). May only be used when​ Image Type Value 1 equals DERIVED.​

C.8.19.3 XA/XRF Acquisition Module​

Table C.8.19.3-1 specifies the Attributes of the XA/XRF Acquisition Module.​

Table C.8.19.3-1. XA/XRF Acquisition Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

KVP​

(0018,0060)​

1​

Average of the peak kilo voltage outputs of the X-Ray generator used for​







all frames.​

Radiation Setting​

(0018,1155)​

1​

Identify the general level of X-Ray dose exposure.​







Enumerated Values:​







SC​low dose exposure generally corresponding to fluoroscopic settings​







(e.g., preparation for diagnostic quality image acquisition)​







GR​high dose for diagnostic quality image acquisition (also called digital​







spot or cine)​

X-RayTubeCurrentinmA​

(0018,9330)​

1C​

Average of the nominal X-Ray tube currents in milliamperes for all frames.​







Required if Exposure in mAs (0018,9332) is not present. May be present​







otherwise.​

Exposure Time in ms​

(0018,9328)​

1C​

Duration of X-Ray exposure in milliseconds. See Section C.8.7.2.1.1.​







Required if Exposure in mAs (0018,9332) is not present. May be present​







otherwise.​

Exposure in mAs​

(0018,9332)​

1C​

The exposure expressed in milliampereseconds, for example calculated​







from Exposure Time and X-Ray Tube Current.​







RequiredifeitherExposureTimeinms(0018,9328)orX-RayTubeCurrent​







in mA (0018,9330) are not present. May be present otherwise.​

Average Pulse Width​

(0018,1154)​

1​

Average width of X-Ray pulse in msec.​

Acquisition Duration​

(0018,9073)​

1​

The time in seconds needed for the complete acquisition.​







See Section C.7.6.16.2.2.1 for further explanation​

Radiation Mode​

(0018,115A)​

1​

Specifies X-Ray radiation mode.​







Defined Terms:​







CONTINUOUS​







PULSED​

Focal Spot(s)​

(0018,1190)​

3​

Nominal focal spot size in mm used to acquire this image.​

Anode Target Material​

(0018,1191)​

3​

The primary material in the anode of the X-Ray source.​







Defined Terms:​

TUNGSTEN​

MOLYBDENUM​

RHODIUM​

- Standard -​

Page 1052​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Rectification Type​

(0018,1156)​

3​

Type of rectification used in the X-Ray generator.​







Defined Terms:​







SINGLE PHASE​







THREE PHASE​







CONSTPOTENTIAL​

X-Ray Receptor Type​

(0018,9420)​

1​

Identifies with type of X-Ray receptor is used.​







Enumerated Values:​







IMG_INTENSIFIER​







DIGITAL_DETECTOR​

Distance Receptor Plane​

(0018,9426)​

2​

Distance in mm between the receptor plane and the detector housing. The​

to Detector Housing​





direction of the distance is positive from receptor plane to X-Ray source.​









Note​









1.​Anegative valueis allowedinthe caseof an imageintensifier​









the receptor plane can be a virtual plane located outside the​









detector housing depending the magnification factor of the​









intensifier. A negative value is not applicable for the digital​









detector.​









2.​Used to calculate the pixel size of the plane in the patient​









when markers are used, and they are placed on the detector​









housing.​

Positioner Type​

(0018,1508)​

1​

Defined Terms:​







CARM​







COLUMN​









Note​









1.​The term CARM can apply to any positioner with 2 degrees​









of freedom of rotation of the X-Ray beam about the Imaging​









Subject.​









2.​The term COLUMN can apply to any positioner with 1 degree​









of freedom of rotation of the X-Ray beam about the Imaging​









Subject.​

C-armPositionerTabletop​

(0018,9474)​

1C​

Describes for C-arm positioner type systems if positioner and tabletop has​

Relationship​





the same geometrical reference system.​

Enumerated Values:​

YES​

NO​

Note​

The value NO is intended for mobile systems where there is no​ table fixed to the system​

Required if Positioner Type (0018,1508) equals CARM.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 1053​

Attribute Name​

Tag​

Type​

Attribute Description​



Acquired Image Area​

(0018,9473)​

2​

X-Ray dose, measured in dGy*cm*cm, to which the patient was exposed​

Dose Product​





for the acquisition of this image only.​



Note​

1.​The sum of the Image Area Dose Product of all images of a​ Series or a Study may not result in the actual area dose​ product to which the patient was exposed.​

2.​Thismaybeanestimatedvaluebasedonassumptionsabout​ the patient's body size and habitus.​

C.8.19.4 X-Ray Image Intensifier Module​

Table C.8.19.4-1 specifies the Attributes of the X-Ray Image Intensifier Module.​

Table C.8.19.4-1. X-Ray Image Intensifier Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Intensifier Size​

(0018,1162)​

1​ Physical diameter of the maximum active area X-Ray intensifier in mm.​







Note​







This Attribute does not specify the field of view. The Attribute Field of​







View Dimension(s) in Float (0018,9461) is intended for this value.​

Intensifier Active Shape​

(0018,9427)​

1​ Shape of the active area used for acquiring this image.​







Enumerated Values:​







RECTANGLE​







ROUND​







HEXAGONAL​







Note​







This may be different from the Field of View Shape (0018,1147), and​







should not be assumed to describe the stored image.​

Intensifier Active​

(0018,9428)​

1​ Dimensions in mm of the active area used for acquiring this image.​

Dimension(s)​





If Intensifier Active Shape (0018,9427) is:​







RECTANGLE: row dimension followed by column.​

ROUND: diameter.​

HEXAGONAL: diameter of the circle circumscribing the hexagon.​

Note​

This may be different from the Field of View Dimension(s) in Float​ (0018,9461),andshouldnotbeassumedtodescribethestoredimage.​

C.8.19.5 X-Ray Detector Module​

Table C.8.19.5-1 contains IOD Attributes that describe an X-Ray detector.​

- Standard -​

Page 1054​ DICOM PS3.3 2020a - Information Object Definitions​

Table C.8.19.5-1. X-Ray Detector Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Include Table C.8-71b “Digital X-Ray Detector Macro Attributes”​



Physical Detector Size​

(0018,9429)​

1​

Dimensions of the physical detector measured in mm as a row​







size followed by a column size.​

Position of Isocenter​

(0018,9430)​

1C​

Position of the Isocenter projection on the detector plane​

Projection​





measured in fractional physical detector elements as a distance​







along the column direction followed by a distance along the row​







direction from the center of the TLHC detector element of a​







rectangle circumscribing the physical detector area.​

Required if Isocenter Reference System Sequence (0018,9462)​ is present.​

C.8.19.6 Enhanced XA/XRF Image Functional Group Macros​

The following sections contain Functional Group Macros specific to the Enhanced XA Image IOD.​

Note​

The Attribute descriptions in the Functional Group Macros are written as if they were applicable to a single frame (i.e., the​ Macro is part of the Per-frame Functional Groups Sequence). If an Attribute is applicable to all frames (i.e., the Macro is part​ of the Shared Functional Groups Sequence) the phrase "this frame" in the Attribute description shall be interpreted to mean​ " for all frames".".​

C.8.19.6.1 X-Ray Frame Characteristics Macro​

Table C.8.19.6-1 specifies the Attributes of the XA/XRF Frame Characteristics Functional Group Macro.​

Table C.8.19.6-1. X-Ray Frame Characteristics Macro Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

XA/XRF Frame Characteristics​

(0018,9412)​

1​

ASequencethatdescribesgeneralcharacteristicsofthisframe.​

Sequence​





Only a single Item shall be included in this Sequence.​







>Derivation Description​

(0008,2111)​

3​

A text description of how this frame was derived.​







See Section C.8.7.1.1.5 for further explanation.​

>Derivation Code Sequence​

(0008,9215)​

3​

A coded description of how this frame was derived. See​







Section C.12.4.1.1 for further explanation.​







One or more Items are permitted in this Sequence.​







More than one Item indicates that successive derivation steps​







have been applied.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 7203 “Image Derivation”.​

>Acquisition Device Processing​

(0018,1400)​

3​

Indicates any visual processing performed on the frame prior to​

Description​





exchange.​

See Section C.8.7.1.1.3.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 1055​

Attribute Name​

Tag​



Type​

Attribute Description​



>Acquisition Device Processing​ (0018,1401)​

3​

Code representing the device-specific processing associated​

Code​







with the frame (e.g., Organ Filtering code)​











Note​











This Codeismanufacturer specific butprovides useful​









annotationinformationtotheknowledgeableobserver.​

C.8.19.6.2 X-Ray Field of View Macro​







Table C.8.19.6-2 specifies the Attributes of the X-Ray Field of View Functional Group Macro.​





Table C.8.19.6-2. X-Ray Field of View Macro Attributes​



Attribute Name​

Tag​

Type​



Attribute Description​



Field of View Sequence​

(0018,9432)​

1​

Sequence containing the field of view for this frame.​









Only a single Item shall be included in this Sequence.​



>Field of View Shape​

(0018,1147)​

3​

Shape of the Field of View, that is the image pixels stored in Pixel Data​







(7FE0,0010).​









Enumerated Values:​









RECTANGLE​









ROUND​











HEXAGONAL​



>Field of View​

(0018,9461)​

3​

Dimensions in mm of the Field of View, that is the image pixels stored in​

Dimension(s) in Float​





Pixel Data (7FE0,0010). If Field of View Shape (0018,1147) is:​







RECTANGLE: row dimension followed by column.​









ROUND: diameter.​









HEXAGONAL: diameter of the circle circumscribing the hexagon.​

>Field of View Origin​

(0018,7030)​

1C​

Offset of the TLHC of a rectangle circumscribing the Field of View, i.e., the​







image pixels stored in Pixel Data (7FE0,0010) before rotation or flipping,​







from the TLHC of the physical detector area measured in physical detector​







pixels as a row offset followed by a column offset.​









See Section C.8.11.4.1.1 for further explanation.​









Required if X-Ray Receptor Type (0018,9420) is present and equals​







DIGITAL_DETECTOR. May be present otherwise.​



>Field of View Rotation​

(0018,7032)​

1​

Clockwise rotation in degrees of Field of View, i.e., the image pixels stored​







in Pixel Data (7FE0,0010), relative to the physical detector.​



Enumerated Values:​

270​

180​

90​

0​

See Section C.8.11.4.1.1 for further explanation.​

- Standard -​
