Page 886​ DICOM PS3.3 2020a - Information Object Definitions​

Table C.8-71. DX Detector Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Include Table C.8-71b “Digital X-Ray Detector Macro​



Attributes”​







Detector Active Time​

(0018,7014)​

3​

Time in mSec that the detector is active during acquisition of this image.​







Note​







This activation window overlaps the time of the X-Ray exposure​







as defined by Exposure Time (0018,1150) and Detector​







Activation Offset From Exposure (0018,7016).​

Detector Activation​

(0018,7016)​

3​

Offset time in mSec that the detector becomes active after the X-Ray​

Offset From Exposure​





beam is turned on during acquisition of this image. May be negative.​

Field of View Shape​

(0018,1147)​

3​

Shape of the Field of View, that is the image pixels stored in Pixel Data​







(7FE0,0010).​







Enumerated Values:​







RECTANGLE​







ROUND​







HEXAGONAL​

Field of View​

(0018,1149)​

3​

Dimensions in mm of the Field of View, that is the image pixels stored in​

Dimension(s)​





Pixel Data (7FE0,0010). If Field of View Shape (0018,1147) is:​







RECTANGLE: row dimension followed by column.​







ROUND: diameter.​







HEXAGONAL: diameter of a circumscribed circle.​

Field of View Origin​

(0018,7030)​

1C​

Offset of the TLHC of a rectangle circumscribing the Field of View, that​







is the image pixels stored in Pixel Data (7FE0,0010), before rotation or​







flipping,fromtheTLHCofthephysicaldetectorareameasuredinphysical​







detector pixels as a row offset followed by a column offset.​







Required if Field of View Rotation (0018,7032) or Field of View Horizontal​







Flip (0018,7034) is present.​







See Section C.8.11.4.1.1 for further explanation.​

Field of View Rotation​

(0018,7032)​

1C​

Clockwise rotation in degrees of Field of View, that is the image pixels​







stored in Pixel Data (7FE0,0010), relative to the physical detector.​

Enumerated Values:​

270​

180​

90​

0​

Required if Field of View Horizontal Flip (0018,7034) is present.​

See Section C.8.11.4.1.1 for further explanation.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 887​

Attribute Name​

Tag​

Type​



Attribute Description​



Field of View Horizontal​

(0018,7034)​

1C​

Whether or not a horizontal flip has been applied to the Field of View, that​

Flip​





istheimagepixelsstoredinPixelData(7FE0,0010),afterrotationrelative​







tothephysicaldetectorasdescribedinFieldofViewRotation(0018,7032).​







Enumerated Values:​









YES​











NO​











Required if Field of View Rotation (0018,7032) is present.​









See Section C.8.11.4.1.1 for further explanation.​



Imager Pixel Spacing​

(0018,1164)​

1​

Physical distance measured at the front plane of the detector housing​







between the center of each image pixel specified by a numeric pair - row​







spacingvalue(delimiter)columnspacingvalueinmm.SeeSection10.7.1.3​







for further explanation of the value order.​









ThevalueofthisAttributeshallneverbeadjustedtoaccountforcorrection​







for the effect of geometric magnification or calibration against an object​







of known size; Pixel Spacing (0028,0030) is specified for that purpose.​

IncludeTable10-10“BasicPixelSpacingCalibrationMacro​





Attributes”​











Cassette ID​

(0018,1007)​

3​

Identifierofthecassettethatcontainsthephotostimulablephosphorplate,​







for CR acquisitions.​



Plate ID​

(0018,1004)​

3​

Identifier of the photostimulable phosphor plate, for CR acquisitions.​

Table C.8-71b contains common Attributes that describe digital X-Ray detector.​





Table C.8-71b. Digital X-Ray Detector Macro Attributes​



Attribute Name​

Tag​

Type​

Attribute Description​



Detector Type​

(0018,7004)​

2​ The type of detector used to acquire this image.​









Defined Terms:​











DIRECT​

X-Ray photoconductor​









SCINTILLATOR​Phosphor used​









STORAGE​

Storage phosphor​









FILM​

Scanned film/screen​



Detector Configuration​

(0018,7005)​

3​ The physical configuration of the detector.​









Defined Terms:​











AREA​single or tiled detector​









SLOT​scanned slot, slit or spot​



Detector Description​

(0018,7006)​

3​ Free text description of detector.​



Detector Mode​

(0018,7008)​

3​ Textdescriptionofoperatingmodeofdetector(implementationspecific).​

Detector ID​

(0018,700A)​

3​ The ID or serial number of the detector used to acquire this image.​

Date of Last Detector​

(0018,700C)​

3​ The date on which the detector used to acquire this image as identified​

Calibration​





in Detector ID (0018,700A) was last calibrated.​



Time of Last Detector​

(0018,700E)​

3​ The time at which the detector used to acquire this image as identified​

Calibration​





in Detector ID (0018,700A) was last calibrated.​



ExposuresonDetectorSince​ (0018,7010)​

3​ TotalnumberofX-Rayexposuresthathavebeenmadeonthedetector​

Last Calibration​





usedtoacquirethisimageasidentifiedinDetectorID(0018,700A)since​







it was calibrated.​



- Standard -​

Page 888​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

ExposuresonDetectorSince​

(0018,7011)​

3​

TotalnumberofX-Rayexposuresthathavebeenmadeonthedetector​

Manufactured​





usedtoacquirethisimageasidentifiedinDetectorID(0018,700A)since​







it was manufactured.​

Detector Time Since Last​

(0018,7012)​

3​

Time in Seconds since an exposure was last made on this detector​

Exposure​





prior to the acquisition of this image.​

Detector Binning​

(0018,701A)​

3​

Number of active detectors used to generate a single pixel. Specified​







as number of row detectors per pixel then column.​

DetectorManufacturerName​

(0018,702A)​

3​

Name of the manufacturer of the detector component of the acquisition​







system​

Detector Manufacturer's​

(0018,702B)​

3​

Model name of the detector component of the acquisition system​

Model Name​







DetectorConditionsNominal​

(0018,7000)​

3​

Whetherornotthedetectorisoperatingwithinnormaltolerancesduring​

Flag​





this image acquisition.​

Enumerated Values:​

YES​

NO​

Note​





Thisflagisintendedtoindicatewhetherornottheremayhave​





been some compromise of the diagnostic quality of the image​





due to some condition such as over-temperature, etc.​

Detector Temperature​

(0018,7001)​

3​ Detector temperature during exposure in degrees Celsius.​

Sensitivity​

(0018,6000)​

3​ Detector sensitivity in manufacturer specific units.​





Note​





1.​This value is intended to provide a single location where​





manufacturer specific information can be found for​





annotation on a display or film, that has meaning to a​





knowledgeable observer.​





2.​This value is manufacturer-specific. DICOM specifies​





Standard Attributes in Table 10-23 'Exposure Index​





Macro', which are recommended.​

Detector Element Physical​

(0018,7020)​

3​ Physical dimensions of each detector element that comprises the​

Size​



detector matrix, in mm.​





Expressed as row dimension followed by column.​





Note​





This may not be the same as Detector Element Spacing​





(0018,7022) due to the presence of spacing material between​





detector elements.​

Detector Element Spacing​

(0018,7022)​

3​ Physicaldistancebetweenthecenterofeachdetectorelement,specified​

by a numeric pair - row spacing value(delimiter) column spacing value​ in mm. See Section 10.7.1.3 for further explanation of the value order.​

Note​

This may not be the same as the Imager Pixel Spacing​ (0018,1164),andshouldnotbeassumedtodescribethestored​ image.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 889​

Attribute Name​

Tag​

Type​

Attribute Description​



Detector Active Shape​

(0018,7024)​

3​ Shape of the active area.​









Enumerated Values:​









RECTANGLE​









ROUND​









HEXAGONAL​









Note​









This may be different from the Field of View Shape​









(0018,1147),andshouldnotbeassumedtodescribethestored​







image.​



DetectorActiveDimension(s)​

(0018,7026)​

3​ Dimensions in mm of the active area.​









If Detector Active Shape (0018,7024) is:​









RECTANGLE: row dimension followed by column.​









ROUND: diameter.​









HEXAGONAL: diameter of a circumscribed circle.​









Note​









This may be different from the Field of View Dimensions​







(0018,1149),andshouldnotbeassumedtodescribethestored​







image.​



Detector Active Origin​

(0018,7028)​

3​ Offset of the TLHC of a rectangle circumscribing the active detector​







area from the TLHC of a rectangle circumscribing the physical detector​

area, measured in physical detector pixels as a row offset followed by​ a column offset.​

See Section C.8.11.4.1.1 for further explanation.​

Include Table 10-23 “Exposure Index Macro Attributes”​

C.8.11.4.1 DX Detector Attribute Descriptions​

C.8.11.4.1.1 Physical, Active, Field of View, Exposed and Displayed Areas​

The relationship between the Physical Detector Area, the Active Detector Area, the Field of View (what is stored in Pixel Data​ (7FE0,0010)), the Exposed Area (after X-Ray Collimation) and the Displayed Area is illustrated in the following diagrams.​

Note​

Some of these Attributes relate the image data to manufacturer specific characteristics of the detector that may be used for​ quality control purposes, e.g., correlation of image artifacts with a detector defect map, analysis of noise performance, etc.​

The Displayed Area is defined in pixel coordinates relative to the stored image pixel values by the Attributes of the Display Shutter​ Module (see Section C.7.6.11). If this Module is not present or supported, then the Displayed Area is equal to the Field of View.​

The Exposed Area is defined in pixel coordinates relative to the stored image pixel values by the Attributes of the X-Ray Collimator​ Module (see Section C.8.7.3).​

For the Digital X-Ray IODs, the Field of View is usually rectangular in shape and usually has the same size as the stored Pixel Data​ (7FE0,0010). The shape and size of the Field of View and the spacing of the pixels are defined by the following Attributes:​

•​Field of View Shape (0018,1147),​

•​Field of View Dimensions (0018,1149),​

- Standard -​

Page 890​

DICOM PS3.3 2020a - Information Object Definitions​

•​Imager Pixel Spacing (0018,1164),​

•​Rows (0028,0010),​

•​Columns (0028,0011).​

In the case where the Field of View has the same size as the stored Pixel Data (7FE0,0010) the following relationships are verified:​

If the Field of View Shape (0018,1147) Attribute equals RECTANGLE:​

•​Field of View Dimensionsrow dimension = Imager Pixel Spacingrow spacing * Rows​

•​Field of View Dimensionscolumn dimension = Imager Pixel Spacingcolumn spacing * Columns​

If the Field of View Shape (0018,1147) Attribute equals ROUND or HEXAGONAL:​

•​Field of View Dimensionsdiameter = Imager Pixel Spacingrow spacing * Rows​

•​Field of View Dimensionsdiameter = Imager Pixel Spacingcolumn spacing * Columns​

The following Attributes define the relationship of the Field of View to the Physical Detector Area:​

•​Field of View Origin (0018,7030),​

•​Field of View Rotation (0018,7032),​

•​Field of View Horizontal Flip (0018,7034).​

For the Digital X-Ray IODs, the Active Area, i.e., that part of the detector matrix that was activated for this exposure, is usually rect-​ angularinshape.TheshapeandsizeoftheActiveAreaandthesizeandspacingofthedetectorsaredefinedbythefollowingAttributes:​

•​Detector Active Shape (0018,7024),​

•​Detector Active Dimensions (0018,7026),​

•​Detector Element Physical Size (0018,7020),​

•​Detector Element Spacing (0018,7022).​

Note​

1.​The Detector Element Physical Size (0018,7020) and Detector Element Spacing (0018,7022) may be different if there​ are insensitive regions between each detector.​

2.​This model of description is not able to accurately describe multiple matrices of detectors that are "tiled" to produce a​ single image.​

The following optional Attribute defines the relationship of the Active Area to the Physical Detector Area:​

•​Detector Active Origin (0018,7028).​

In the case where the Field of View has the same size as the stored Pixel Data (7FE0,0010), the relationship between detectors and​ stored image pixels is defined by Detector Binning (0018,701A), which specifies how many detectors, in each of the row and column​ directions, contribute to (are pooled or averaged to form) a single stored image pixel.​

Note​

1.​Detector Binning (0018,701A) may have values less than one if sub-sampling is used to derive an image with higher​ spatial resolution than the detector matrix.​

2.​The detector binning results in the size of a stored image pixel being different from the contributing physical detector​ pixels. In this case it is important to notice that the Field Of View Origin (0018,7030) is defined with respect to the center​ of the detector element located at the TLHC of the Field of View.​

- Standard -​
