Page 796​

Attribute Name​

Tag​

Type​

Attribute Description​

>>>Referenced Source​

(3008,0142)​

2​

IdentificationnumberoftheSourceApplicator.ThevalueofSource​

Applicator Number​

ApplicatorNumber(300A,0290)shallbeuniquewithintheChannel​

in which it is created.​

>>>Source Applicator ID​

(300A,0291)​

2​

User or machine supplied identifier for Source Applicator.​

>>>Source Applicator Type​

(300A,0292)​

1​

Type of Source Applicator.​

Defined Terms:​

FLEXIBLE​

RIGID​

>>>Source Applicator Name​

(300A,0294)​

3​

User-defined name for Source Applicator.​

>>>Source Applicator Length​

(300A,0296)​

1​

LengthofSourceApplicator(mm),definedasthedistancebetween​

the connector of the applicator and the distal-most position of the​

source.​

>>>SourceApplicatorTipLength​

(300A,0274)​

2C​

Length of Source Applicator Tip (in mm), defined as the distance​

between the outer tip of the applicator and the center of the​

distal-most possible position of the source.​

Required if Channel Effective Length (300A,0271) is present.​

See Section C.8.8.15.16.​

>>>Source Applicator​

(300A,0298)​

3​

Manufacturer of Source Applicator.​

Manufacturer​

>>>Source Applicator Step Size​

(300A,02A0)​

1C​

Distance of path along channel (mm) between adjacent (potential)​

dwell positions. Required if Source Movement Type (300A,0288)​

is STEPWISE.​

>>Transfer Tube Number​

(300A,02A2)​

2​

Identification number of the Transfer Tube. The value of Transfer​

Tube Number (300A,02A2) shall be unique within the Channel in​

which it is created.​

>>Transfer Tube Length​

(300A,02A4)​

2C​

Length of Transfer Tube of current afterloading Channel (mm).​

Required if value Transfer Tube Number (300A,02A2) is not zero​

length.​

>>Recorded Channel Shield​

(3008,0150)​

3​

Sequence of Channel Shields associated with current Channel.​

Sequence​

One or more Items are permitted in this Sequence.​

See RT Plan IOD for description of Channel Shields.​

>>>Referenced Channel Shield​

(3008,0152)​

2​

Identification number of the Channel Shield. The value of Channel​

Number​

Shield Number (300A,02B2) shall be unique within the Channel in​

which it is created.​

>>>Channel Shield ID​

(300A,02B3)​

2​

User or machine supplied identifier for Channel Shield.​

>>>Channel Shield Name​

(300A,02B4)​

3​

User-defined name for Channel Shield.​

>>Referenced Source Number​

(300C,000E)​

1​

Uniquely identifies the referenced Source within the Recorded​

Source Sequence (3008,0100) for current Application Setup.​

>>Safe Position Exit Date​

(3008,0162)​

1C​

Date on which the source(s) exited the safe. Required if Recorded​

Channel Sequence (3008,0130) is present and Brachy Treatment​

Type (300A,0202) is not MANUAL or PDR.​

>>Safe Position Exit Time​

(3008,0164)​

1C​

Timeonwhichthesource(s)exitedthesafe.RequiredifRecorded​

Channel Sequence (3008,0130) is present and Brachy Treatment​

Type (300A,0202) is not MANUAL or PDR.​

Page 797​

Attribute Name​

Tag​

Type​

Attribute Description​

>>Safe Position Return Date​

(3008,0166)​

1C​

Date on which the source(s) returned to the safe. Required if​

Recorded Channel Sequence (3008,0130) is present and Brachy​

Treatment Type (300A,0202) is not MANUAL or PDR.​

>>Safe Position Return Time​

(3008,0168)​

1C​

Time on which the source(s) returned to the safe. Required if​

Recorded Channel Sequence (3008,0130) is present and Brachy​

Treatment Type (300A,0202) is not MANUAL or PDR.​

>>Number of Control Points​

(300A,0110)​

1​

Number of control points in Channel. For an N-segment Channel​

there will be 2N (stepwise movement) or N+1 (continuous​

movement) control points.​

>>BrachyControlPointDelivered​

(3008,0160)​

1​

Sequence of machine configurations describing this Channel.​

Sequence​

The number of Items in this Sequence shall equal the value of​

Number of Control Points (300A,0110).​

See RT Plan IOD and Section C.8.8.22.1 for description of Brachy​

Control Point Delivered Sequence.​

>>>Referenced Control Point​

(300C,00F0)​

3​

Index of current Control Point, starting at 0 for first Control Point.​

Index​

>>>TreatmentControlPointDate​

(3008,0024)​

1​

Date when the delivery of radiation at this control point began. For​

the final control point this shall be the Date when the previous​

control point ended.​

>>>TreatmentControlPointTime​

(3008,0025)​

1​

Time when the delivery of radiation at this control point began. For​

the final control point this shall be the Time when the previous​

control point ended.​

>>>Control Point Relative​

(300A,02D2)​

1​

Distance in mm between current Control Point Position and the​

Position​

center of the distal-most possible Source position in current​

Channel. See RT Plan IOD.​

>>>Override Sequence​

(3008,0060)​

3​

Sequence of parameters that were overridden during the​

administration of the treatment immediately prior to the current​

control point.​

One or more Items are permitted in this Sequence.​

>>>>OverrideParameterPointer​

(3008,0062)​

2​

ContainstheDataElementTagoftheAttributethatwasoverridden.​

>>>>Operators' Name​

(0008,1070)​

2​

Name of operator who authorized override.​

>>>>Operator Identification​

(0008,1072)​

3​

Identificationoftheoperatorwhoauthorizedoverride.Onlyasingle​

Sequence​

Item is permitted in this Sequence.​

>>>>>Include Table 10-1 “Person Identification Macro Attributes​

Description”​

>>>>Override Reason​

(3008,0066)​

3​

User-defined description of reason for override of parameter​

specified by Override Parameter Pointer (3008,0062).​

>>Pulse Specific Brachy Control​

(3008,0171)​

3​

BrachyControlPointDeliveredSequenceforeachPDRtreatment​

Point Delivered Sequence​

pulse.​

Number of Items in the Sequence shall be equal to the Delivered​

Number of Pulses (3008,0138).​

>>>Pulse Number​

(3008,0172)​

1​

Identification Number of this delivered Pulse.​

The pulse numbers for a treatment start at 1 and increase​

monotonicallyby1.AgivenSOPinstancemightonlycontainsome​

of the pulses of the given treatment.​

>>>Safe Position Exit Date​

(3008,0162)​

1​

Date on which the source(s) exited the safe.​

>>>Safe Position Exit Time​

(3008,0164)​

1​

Time at which the source(s) exited the safe.​

Page 798​

Attribute Name​

Tag​

Type​

Attribute Description​

>>>Safe Position Return Date​

(3008,0166)​

1​ Date on which the source(s) returned to the safe.​

>>>Safe Position Return Time​

(3008,0168)​

1​ Time at which the source(s) returned to the safe.​

>>>Brachy Pulse Control Point​

(3008,0173)​

1​ List of control points for this pulse.​

Delivered Sequence​

See Section C.8.8.22.1.​

>>>>Referenced Control Point​

(300C,00F0)​

3​ Index of current Control Point, starting at 0 for first Control Point​

Index​

in this Sequence.​

>>>>Treatment Control Point​

(3008,0024)​

1​ Date when the delivery of radiation at this control point began.​

Date​

For the final control point, this shall be the Date when the previous​

control point ended.​

>>>>Treatment Control Point​

(3008,0025)​

1​ Time when the delivery of radiation at this control point began.​

Time​

For the final control point, this shall be the Time when the previous​

control point ended.​

>>>>Control Point Relative​

(300A,02D2)​

1​ Distance in mm between current Control Point Position and the​

Position​

center of the distal-most possible Source position in current​

Channel.​

See Section C.8.8.15.9.​

>>>>Override Sequence​

(3008,0060)​

3​ Parameters which were overridden during the administration of​

the treatment immediately prior to the current control point.​

One or more Items are permitted in this Sequence.​

>>>>>Override Parameter​

(3008,0062)​

2​ Data Element Tag of the Attribute that was overridden.​

Pointer​

>>>>>Operators' Name​

(0008,1070)​

2​ Name of operator who authorized override.​

>>>>>Operator Identification​

(0008,1072)​

3​ Identificationoftheoperatorwhoauthorizedoverride.Onlyasingle​

Sequence​

Item is permitted in this Sequence.​

>>>>>>IncludeTable10-1“PersonIdentificationMacroAttributes​

Description”​

>>>>>Override Reason​

(3008,0066)​

3​ User-defined description of reason for override.​

DICOM PS3.3 2020a - Information Object Definitions​
