Page 646​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

>Calibration Data Sequence​

(0054,0306)​

3​

Sequence that contains calibration data.​







One or more Items are permitted in this Sequence.​

>>Energy Window Number​

(0054,0308)​

1​

TheItemnumberintheEnergyWindowInformationSequence​







to which the following calibration data relates. The Items are​







numbered starting from 1.​

>>Syringe Counts​

(0018,1045)​

3​

Pre-injection syringe count rate in counts/sec. See​







Section C.8.4.10.1.8 for further explanation.​

>>Residual Syringe Counts​

(0054,0017)​

3​

Post-injection residue syringe count rate in counts/sec. See​







Section C.8.4.10.1.9 for further explanation.​

>Radiopharmaceutical​

(0018,0031)​

3​

Name of the radiopharmaceutical.​

>Radiopharmaceutical Code​

(0054,0304)​

3​

Sequence that identifies the radiopharmaceutical.​

Sequence​





Only a single Item is permitted in this Sequence.​







>>Include Table 8.8-1 “Code Sequence Macro Attributes”​



BCID 25 “Radiopharmaceuticals”.​







Code Meaning (0008,0104) shall be Type 3 for historical​







reasons.​

Intervention Drug Information​

(0018,0026)​

3​

SequenceofItemsthatdescribestheinterventiondrugsused.​

Sequence​





One or more Items are permitted in this Sequence.​

>Intervention Drug Name​

(0018,0034)​

3​

Name of intervention drug.​

>Intervention Drug Code​

(0018,0029)​

3​

Sequence that identifies the intervention drug name.​

Sequence​





Only a single Item is permitted in this Sequence.​







>>Include Table 8.8-1 “Code Sequence Macro Attributes”​



BCID 10 “Interventional Drug”.​







Code Meaning (0008,0104) shall be Type 3 for historical​







reasons.​

>Administration Route Code​

(0054,0302)​

3​

Sequence that identifies the administration route for the​

Sequence​





intervention drug.​







Only a single Item is permitted in this Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​



BCID 11 “Route of Administration”.​







Code Meaning (0008,0104) shall be Type 3 for historical​







reasons.​

>Intervention Drug Start Time​

(0018,0035)​

3​

Time of administration of the intervention drug, using the​







same time base as for Acquisition Time (0008,0032).​

>Intervention Drug Stop Time​

(0018,0027)​

3​

Timeofcompletionofadministrationoftheinterventiondrug,​







using the same time base as for Acquisition Time​







(0008,0032).​

>Intervention Drug Dose​

(0018,0028)​

3​

Intervention drug dose, in mg.​

C.8.4.10.1 NM Isotope Module Attribute Descriptions​

C.8.4.10.1.1 Energy Window Lower Limit​

Energy Window Lower Limit (0054,0014) is the acquisition energy window lower limit in KeV for acceptance of scintillation events into​ this Isotope.​

C.8.4.10.1.2 Energy Window Upper Limit​

Energy Window Upper Limit (0054,0015) is the acquisition energy window upper limit in KeV for acceptance of scintillation events​ into this Isotope.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​

Page 647​

C.8.4.10.1.3 (Retired)​

C.8.4.10.1.4 (Retired)​

C.8.4.10.1.5 Radiopharmaceutical Start Time​

RadiopharmaceuticalStartTime(0018,1072)istheactualtimeofradiopharmaceuticaladministrationtothepatientforimagingpurposes,​ using the same time base as for Acquisition Time (0008,0032).​

C.8.4.10.1.6 Radiopharmaceutical Stop Time​

RadiopharmaceuticalStopTime(0018,1073)istheactualendingtimeofradiopharmaceuticaladministrationtothepatientforimaging​ purposes, using the same time base as for Acquisition Time (0008,0032).​

C.8.4.10.1.7 Radionuclide Total Dose​

Radionuclide Total Dose (0018,1074) is the radiopharmaceutical dose administered to the patient measured in MegaBecquerels​ (Mbq) at the Radiopharmaceutical Start Time.​

C.8.4.10.1.8 Syringe Counts​

Syringe Counts (0018,1045) is the pre-injection syringe acquisition count rate measured in counts/sec, corrected to Acquisition Time​ (0008,0032) if necessary.​

C.8.4.10.1.9 Residual Syringe Counts​

ResidualSyringeCounts(0054,0017)isthesyringeacquisitioncountratefollowingpatientinjection,measuredincounts/sec,corrected​ to Acquisition Time (0008,0032) if necessary.​

C.8.4.10.1.10 (Retired)​

C.8.4.10.1.11 (Retired)​

C.8.4.11 NM Detector Module​

Table C.8-11 contains IOD Attributes that describe Nuclear Medicine Detectors used to produce an image.​

Table C.8-11. NM Detector Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Detector Information​

(0054,0022)​

2​ Sequence of Items that describe the detectors used.​

Sequence​





Zero or more Items shall be included in this Sequence.​













ThenumberofItemsshallbeequaltoNumberofDetectors(0054,0021).​







The first Item corresponds to frames with value of 1 in Detector Vector​







(0054,0020), the second Item with value 2, etc.​

>Collimator/Grid Name​

(0018,1180)​

3​ Label describing the collimator used (LEAP, hires, etc.)​

>Collimator Type​

(0018,1181)​

2​

Collimator type.​







Defined Terms:​

PARA​Parallel (default)​

PINH​Pinhole​

FANB​Fan-beam​

CONE​Cone-beam​

SLNT​Slant hole​

ASTG​Astigmatic​

DIVG​Diverging​

NONE​No collimator​

UNKN​Unknown​

- Standard -​

Page 648​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

>Field of View Shape​

(0018,1147)​

3​

Shape of the field of view of the Nuclear Medicine detector.​







Defined Terms:​







RECTANGLE​







ROUND​







HEXAGONAL​

>Field of View​

(0018,1149)​

3​

Dimensions of the field of view, in mm. If Field of View Shape​

Dimension(s)​





(0018,1147) is:​







RECTANGLE: row dimension followed by column.​







ROUND: diameter.​







HEXAGONAL: diameter of a circumscribed circle.​

>Focal Distance​

(0018,1182)​

2​

Focal distance, in mm. A value of 0 means infinite distance for parallel​







collimation. See Section C.8.4.11.1.1 for further specialization.​

>X Focus Center​

(0018,1183)​

3​

Center of focus along a row. See Section C.8.4.11.1.2 for further​







explanation.​

>Y Focus Center​

(0018,1184)​

3​

Center of focus along a column. See Section C.8.4.11.1.2 for further​







explanation.​

>Zoom Center​

(0028,0032)​

3​

Theamountofoffsetfrom(0,0)appliedtoeachpixelintheimagebefore​







application of the zoom factor, specified by a numeric pair: row value​







(delimiter) column value (in mm). See Section C.8.4.11.1.3 for further​







explanation.​

>Zoom Factor​

(0028,0031)​

3​

Theamountofmagnificationappliedtoeachpixelintheimage,specified​







by a numeric pair: row value (delimiter) column value. See​







Section C.8.4.11.1.4 for further explanation.​

>Center of Rotation Offset​

(0018,1145)​

3​

Average center of rotation offset of Nuclear Medicine detector in mm.​







See Section C.8.4.11.1.5 for further explanation.​

>Gantry/Detector Tilt​

(0018,1120)​

3​

Angle of tilt in degrees of the detector. See Section C.8.4.11.1.6 for​







further explanation.​

>Distance Source to​

(0018,1110)​

2C​

Distanceinmmfromtransmissionsourcetothedetectorface.Required​

Detector​





if Image Type (0008,0008) Value 4 is TRANSMISSION and Value 3 is​







not any of TOMO, GATED TOMO, RECON TOMO or RECON GATED​







TOMO.​

>Start Angle​

(0054,0200)​

3​

Position of the detector about the patient for the start of the acquisition,​







in degrees. Zero degrees is referenced to the origin at the patient's​







back. Viewing from the patient's feet, angle increases in a​







counter-clockwise direction (detector normal rotating from the patient's​







back towards the patient's left side). Should not be included if Image​







Type (0008,0008) Value 3 is TOMO, GATED TOMO, RECON TOMO​







or RECON GATED TOMO.​

>Radial Position​

(0018,1142)​

3​

Radialdistanceofthedetectorfromthecenterofrotation,inmm.Should​







not be included if Image Type (0008,0008) Value 3 is TOMO, GATED​







TOMO, RECON TOMO or RECON GATED TOMO.​

>Image Orientation​

(0020,0037)​

2​

The direction cosines of the first row and the first column with respect​

(Patient)​





to the patient. See Section C.7.6.2.1.1 for further explanation.​

>Image Position (Patient)​

(0020,0032)​

2​

The x, y, and z coordinates of the upper left hand corner (center of the​







first voxel transmitted) of the image, in mm. See Section C.7.6.2.1.1 for​







further explanation.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 649​

Attribute Name​

Tag​

Type​

Attribute Description​



>View Code Sequence​

(0054,0220)​

3​

Sequencethatdescribestheprojectionoftheanatomicregionofinterest​







on the image receptor.​









Only a single Item is permitted in this Sequence.​



>>Include Table 8.8-1 “Code Sequence Macro Attributes”​ BCID 26 “Nuclear Medicine Projections”.​









Code Meaning (0008,0104) shall be Type 3 for historical reasons.​

>>View Modifier Code​

(0054,0222)​

2C​

View Modifier. Required if needed to fully specify the View.​

Sequence​

Zero or one Item shall be included in this Sequence.​

>>>Include Table 8.8-1 “Code Sequence Macro Attributes”​BCID 23 “Cranio-Caudad Angulation”.​

Code Meaning (0008,0104) shall be Type 3 for historical reasons.​

C.8.4.11.1 NM Detector Attribute Descriptions​

C.8.4.11.1.1 Focal Distance​

Focal Distance (0018,1182) for NM Image data is the focal distance, in mm for converging or diverging collimators, measured from​ the front face of the detector to the focus. Positive values indicate converging and negative values indicate diverging collimators. A​ value of 0 means infinite distance for parallel collimation.​

C.8.4.11.1.2 Focus Center​

X Focus Center (0018,1183) and Y Focus Center (0018,1184) for NM Image data is used to define the projection of the focus for a​ converging or diverging collimator within the un-zoomed Field of View. It is defined in mm for row and column relative to the center​ of the un-zoomed Field of View.​

C.8.4.11.1.3 Zoom Center​

Zoom Center (0028,0032) is the offset between the un-zoomed camera field of view and field of view, measured from the center of​ the un-zoomed camera field of view to the center the of the zoomed field of view. The offset is measured in mm in the un-zoomed​ camera FOV dimensions. Positive values are to the right and down from the un-zoomed center, as viewed from the image plane.​ When this Attribute is not given, the Zoom Center is assumed to be 0\0.​

C.8.4.11.1.4 Zoom Factor​

ZoomFactor(0028,0031)isthemagnificationfactorthatwasusedduringtheacquisition.WhenthisAttributeisnotgiven,itisassumed​ to be 1.0\1.0.​

Note​

Zoom Factor (0028,0031) is informational only. Pixel Spacing (0028,0030) already takes account of this and any other​ changes to pixel size.​

C.8.4.11.1.5 Center of Rotation Offset​

Center of Rotation Offset (0018,1145) is the average amount of offset in mm between the Detector Field of View center and the​ physicalcenterofrotationofthegantryforcircularorbitalscans.Positivevaluesindicatethephysicalcenteristotherightoftheimage​ plane center.​

If:​

1.​Image Type (0008,0008) Value 3 is TOMO or GATED TOMO, and​

2.​Corrected Image (0028,0051) does not include the value "COR", and​

3.​Center of Rotation Offset (0018,1145) is non-zero,​

then the receiver should assume that Center of Rotation correction has not already been done.​

- Standard -​

Page 650​

DICOM PS3.3 2020a - Information Object Definitions​

If the Center of Rotation Offset is zero, no correction shall be applied.​

C.8.4.11.1.6 Gantry/Detector Tilt​

Gantry/Detector Tilt (0018,1120) for NM Image data is the angle in degrees of the detector face relative to the patient's major (Head​ to Feet) axis (or the table supporting the patient). Positive tilt is towards the patient's feet.​

C.8.4.12 NM Tomo Acquisition Module​

ThisModuleappliestoaTOMOMulti-frameImage.ThisModuleispresentwhenImageType(0008,0008)Value3,isequaltoTOMO,​

GATEDTOMO,RECONTOMO,orRECONGATEDTOMO.TheelementsfoundinthisModuledescribetheacquisitionoftheImage.​

Table C.8-12. NM Tomo Acquisition Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Rotation Information​

(0054,0052)​

2​

Sequence of Items that describe TOMO rotational groups. A new rotation​

Sequence​





is defined whenever the direction of the detector motion changes, or Table​







Traverse (0018,1131) changes.​







Zero or more Items shall be included in this Sequence.​







The number of Items shall be equal to Number of Rotations (0054,0051).​







If Rotation Vector (0054,0050) is present, the first Item corresponds to​







frames with value of 1 in Rotation Vector (0054,0050), the second Item​







with value 2, etc.​

>Start Angle​

(0054,0200)​

1​

Position of the detector about the patient for the start of this rotation, in​







degrees. Zero degrees is referenced to the origin at the patient's back.​







Viewing from the patient's feet, angle increases in a counter-clockwise​







direction (detector normal rotating from the patient's back towards the​







patient's left side).​

>Angular Step​

(0018,1144)​

1​

The angular scan arc step between views of the TOMO acquisition, in​







degrees. See Section C.8.4.12.1.1 for further explanation.​

>Rotation Direction​

(0018,1140)​

1​

Direction of rotation of the detector about the patient. See Start Angle​







(0054,0200) for further explanation of direction.​







Enumerated Values:​







CW​clockwise (decreasing angle)​







CC​counter-clockwise (increasing angle).​

>Scan Arc​

(0018,1143)​

1​

The effective angular range of the scan data in degrees. The value shall​







be positive.​

>Actual Frame Duration​

(0018,1242)​

1​

Nominal acquisition time per angular position, in msec.​

>Radial Position​

(0018,1142)​

3​

Radial distance of the detector from the center of rotation, in mm. It shall​







haveasinglevaluethatisanaveragevalueforthisrotation,oritshallhave​







one value per angular view.​

>Distance Source to​

(0018,1110)​

2C​

Distance in mm from transmission source to the detector face. Required if​

Detector​





Image Type (0008,0008) Value 4 is TRANSMISSION.​

>Number of Frames in​

(0054,0053)​

1​

Number of angular views in this rotation.​

Rotation​







>Table Traverse​

(0018,1131)​

3​

Location of the patient table (or gantry relative to the table) in mm. The​







range and values of this element are determined by the manufacturer.​

>Table Height​

(0018,1130)​

3​

The distance in mm of the top of the patient table to the center of rotation.​







Table height below the center of rotation has a positive value.​

- Standard -​

Смотрите также:

«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
Значение, сущность и содержание социально — педагогической деятельности в организации для детей-сирот и детей, оставшихся без попечения родителей
__RGR2
__RGR2
_11_А. Франс для эл версии
_индив анализ данных
- Интерфейс 485 и оптопорт 11
:Конвергентный подход к проектированию дополнительных общеобразовательных общеразвивающих программ
