DICOM PS3.2 2020a - Conformance​

Page 41​

Note​

IODs from a Standard Extended SOP Class may be freely exchanged between DICOM​

implementations since implementations that do not recognize the additional Type 3​

Attributes would simply ignore them.​

Specialized SOP Class​

ASOPClassderivedfromaStandardSOPClassthathasbeenspecializedinanimplementation​

by additional Type 1, 1C, 2, 2C, or 3 Attributes, by enumeration of specific permitted values for​

Attributes,orbyenumerationofspecificpermittedTemplates.TheadditionalAttributesmayeither​

be drawn from the Data Dictionary in PS3.6, or may be Private Attributes. The enumeration of​

permittedAttributevaluesorTemplatesshallbeasubsetofthosepermittedintherelatedStandard​

SOP Class. Since the semantics of the related Standard SOP Class may be modified by the​

additional Attributes, a Specialized SOP Class utilizes a Privately Defined UID that differs from​

the UID for the related Standard SOP Class.​

Note​

1.​Since a Specialized SOP Class has a different UID than a Standard or Standard​

Extended SOP Class, other DICOM implementations may not recognize the​

SpecializedSOPClass.Becauseofthislimitation,aSpecializedSOPClassshould​

only be used when a Standard or Standard Extended SOP Class would not be​

appropriate. Before different implementations can exchange Instances in a​

Specialized SOP Class, the implementations must agree on the UID, content (in​

particular the additional Type 1, 1C, 2, and 2C Attributes), and semantics of the​

Specialized SOP Class. A Specialized SOP Class may be used to create a new or​

experimental SOP Class that is closely related to a Standard SOP Class.​

2.​TheAssociationNegotiationforaSpecializedSOPClassmayincludeaSOPClass​

Common Extended Negotiation Sub-Item (as defined in PS3.7) for identification of​

the Service Class and of the Related General SOP Class from which it was​

specialized. This may allow a receiving application, without prior agreement on the​

Specialized SOP Class IOD, to process Instances of that class as if they were​

instances of a Related General SOP Class.​

Private SOP Class​

A SOP Class that is not defined in the DICOM Standard, but is published in an implementation's​

Conformance Statement.​

Note​

Since a Private SOP Class is not defined in the DICOM Standard, other DICOM​

implementations may not recognize the Private SOP Class. Because of this limitation,​

a Private SOP Class should only be used when a Standard or Standard Extended SOP​

Class would not be appropriate. In order for different implementations to exchange​

Instances in a Private SOP Class, the implementations must agree on the UID, content​

(in particular the Type 1, 1C, 2, and 2C Attributes), and semantics of the Private SOP​

Class. A Private SOP class may be used to create a totally new or experimental SOP​

Class.​

Standard Attribute​

An Attribute defined in the Data Dictionary in PS3.6.​

Private Attribute​

An Attribute that is not defined in the DICOM Standard.​

Standard Application Profile​

An Application Profile defined in the DICOM Standard that is used in an implementation with no​

modifications.​

Augmented Application Profile​

An Application Profile derived from a Standard Application Profile by incorporating support for​

additional Standard or Standard Extended SOP Classes.​

Private Application Profile​

An Application Profile that is not defined in the DICOM Standard, but is published in an​

implementation's Conformance Statement.​

Page 42​

DICOM PS3.2 2020a - Conformance​

Security Profile​

A mechanism for selecting an appropriate set of choices from the Parts of the DICOM Standard​

along with corresponding security mechanisms (e.g., encryption algorithms) for the support of​

security facilities.​

Transformation of DICOM SR to​

A mechanism for mapping and transforming DICOM SR objects to HL7 CDA documents.​

CDA​

ACR​

American College of Radiology​

ACSE​

Association Control Service Element​

AE​

Application Entity​

ANSI​

American National Standards Institute​

AP​

Application Profile​

API​

Application Programming Interface​

ASCII​

American Standard Code for Information Interchange​

CEN TC251​Comite Europeen de Normalisation-Technical Committee 251-Medical Informatics​

DICOM​

Digital Imaging and Communications in Medicine​

DIMSE​

DICOM Message Service Element​

DIMSE-C​

DICOM Message Service Element-Composite​

DIMSE-N​

DICOM Message Service Element-Normalized​

FSC​

File-set Creator​

FSR​

File-set Reader​

FSU​

File-set Updater​

HISPP​

Healthcare Informatics Standards Planning Panel​

HL7​

Health Level 7​

IE​

Information Entity​

IEEE​

Institute of Electrical and Electronics Engineers​

IOD​

Information Object Definition​

ISO​

International Standards Organization​

ISP​

International Standardized Profile​

JIRA​

Japan Medical Imaging and Radiological Systems Industries Association​

MSDS​

Healthcare Message Standard Developers Sub-Committee​

NEMA​

National Electrical Manufacturers Association​

OSI​

Open Systems Interconnection​

PDU​

Protocol Data Unit​

REST​

Representational State Transfer​

RESTful​

A RESTful Web service is a Web service implemented using REST architecture and HTTP (see http://www.ics.uci.edu/​

~fielding/pubs/dissertation/fielding_dissertation.pdf)​
