Page 56​

DICOM PS3.2 2020a - Conformance​



SOP Classes​

User of Service (SCU)​

Provider of Service (SCP)​

CT Image Storage​

Yes​

No​

US Image Storage​

Yes​

Yes​

Query/Retrieve​





Patient Root Information Model FIND​

Option​

No​

Notes, Reports, Measurements Transfer​





Comprehensive SR, and specializations​

No​

Yes​

…​





The services can be specified as a SCU, SCP or as an Option, which means that it is either configurable or that it can be purchased​ separately.​

Note​

Verification SCP (C-Echo) is not included in the table above because it is required for any Acceptor of an Association. The​ Verification SCU details are covered in the details of the conformance statement.​

The SOP Classes are categorized as follows:​

Table A.1-2. UID Values​

UID Value​

UID Name​

Category​

1.2.840.10008.1.20.1​

Storage Commitment Push Model SOP Class​

Workflow Management​

1.2.840.10008.1.40​

Procedural Event Logging SOP Class​

Workflow Management​

1.2.840.10008.1.42​

Substance Administration Logging SOP Class​

Workflow Management​

1.2.840.10008.3.1.2.3.3​

Modality Performed Procedure Step SOP Class​

Workflow Management​

1.2.840.10008.3.1.2.3.4​

Modality Performed Procedure Step Retrieve SOP Class​Workflow Management​

1.2.840.10008.3.1.2.3.5​

ModalityPerformedProcedureStepNotificationSOPClass​Workflow Management​

1.2.840.10008.4.2​

Storage Service Class​

Transfer​

1.2.840.10008.5.1.1.1​

Basic Film Session SOP Class​

Print Management​

1.2.840.10008.5.1.1.2​

Basic Film Box SOP Class​

Print Management​

1.2.840.10008.5.1.1.4​

Basic Grayscale Image Box SOP Class​

Print Management​

1.2.840.10008.5.1.1.4.1​

Basic Color Image Box SOP Class​

Print Management​

1.2.840.10008.5.1.1.9​

Basic Grayscale Print Management Meta SOP Class​

Print Management​

1.2.840.10008.5.1.1.14​

Print Job SOP Class​

Print Management​

1.2.840.10008.5.1.1.15​

Basic Annotation Box SOP Class​

Print Management​

1.2.840.10008.5.1.1.16​

Printer SOP Class​

Print Management​

1.2.840.10008.5.1.1.16.376​

Printer Configuration Retrieval SOP Class​

Print Management​

1.2.840.10008.5.1.1.18​

Basic Color Print Management Meta SOP Class​

Print Management​

1.2.840.10008.5.1.1.23​

Presentation LUT SOP Class​

Print Management​

1.2.840.10008.5.1.1.24.1​

Basic Print Image Overlay Box SOP Class​

Print Management​

1.2.840.10008.5.1.1.33​

Media Creation Management SOP Class​

Print Management​

1.2.840.10008.5.1.4.1.1.1​

Computed Radiography Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.1.1​

DigitalX-RayImageStorage-ForPresentationSOPClass​Transfer​

1.2.840.10008.5.1.4.1.1.1.1.1​

Digital X-Ray Image Storage - For Processing SOP Class​Transfer​

1.2.840.10008.5.1.4.1.1.1.2​

Digital Mammography X-Ray Image Storage - For​

Transfer​



Presentation SOP Class​



- Standard -​



DICOM PS3.2 2020a - Conformance​

Page 57​

UID Value​

UID Name​

Category​

1.2.840.10008.5.1.4.1.1.1.2.1​

Digital Mammography X-Ray Image Storage - For​

Transfer​



Processing SOP Class​



1.2.840.10008.5.1.4.1.1.1.3​

Digital Intra-oral X-Ray Image Storage - For Presentation​Transfer​



SOP Class​



1.2.840.10008.5.1.4.1.1.1.3.1​

Digital Intra-oral X-Ray Image Storage - For Processing​ Transfer​



SOP Class​



1.2.840.10008.5.1.4.1.1.2​

CT Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.2.1​

Enhanced CT Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.3.1​

Ultrasound Multi-frame Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.4​

MR Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.4.1​

Enhanced MR Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.4.2​

MR Spectroscopy Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.4.3​

Enhanced MR Color Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.6.1​

Ultrasound Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.6.2​

Enhanced US Volume Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.7​

Secondary Capture Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.7.1​

Multi-frame Single Bit Secondary Capture Image Storage​Transfer​



SOP Class​



1.2.840.10008.5.1.4.1.1.7.2​

Multi-frame Grayscale Byte Secondary Capture Image​

Transfer​



Storage SOP Class​



1.2.840.10008.5.1.4.1.1.7.3​

Multi-frame Grayscale Word Secondary Capture Image​ Transfer​



Storage SOP Class​



1.2.840.10008.5.1.4.1.1.7.4​

Multi-frame True Color SecondaryCaptureImageStorage​Transfer​



SOP Class​



1.2.840.10008.5.1.4.1.1.9.1.1​

12-lead ECG Waveform Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.9.1.2​

General ECG Waveform Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.9.1.3​

Ambulatory ECG Waveform Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.9.2.1​

Hemodynamic Waveform Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.9.3.1​

Cardiac Electrophysiology Waveform Storage SOP Class​Transfer​

1.2.840.10008.5.1.4.1.1.9.4.1​

Basic Voice Audio Waveform Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.9.4.2​

General Audio Waveform Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.9.5.1​

Arterial Pulse Waveform Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.9.6.1​

Respiratory Waveform Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.11.1​

GrayscaleSoftcopyPresentationStateStorageSOPClass​Transfer​

1.2.840.10008.5.1.4.1.1.11.2​

Color Softcopy Presentation State Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.11.3​

Pseudo-Color Softcopy Presentation State Storage SOP​Transfer​



Class​



1.2.840.10008.5.1.4.1.1.11.4​

Blending Softcopy Presentation State Storage SOP Class​Transfer​

1.2.840.10008.5.1.4.1.1.11.5​

XA/XRF Grayscale Softcopy Presentation State Storage​Transfer​



SOP Class​



1.2.840.10008.5.1.4.1.1.11.6​

Grayscale Planar MPR Volumetric Presentation State​

Transfer​



Storage SOP Class​



1.2.840.10008.5.1.4.1.1.11.7​

Compositing Planar MPR Volumetric Presentation State​Transfer​



Storage SOP Class​



1.2.840.10008.5.1.4.1.1.11.8​

AdvancedBlendingPresentationStateStorageSOPClass​Transfer​

- Standard -​

Page 58​

DICOM PS3.2 2020a - Conformance​



UID Value​

UID Name​

Category​

1.2.840.10008.5.1.4.1.1.11.9​

Volume Rendering Volumetric Presentation State Storage​Transfer​



SOP Class​



1.2.840.10008.5.1.4.1.1.11.10​

Segmented Volume Rendering Volumetric Presentation​ Transfer​



State Storage SOP Class​



1.2.840.10008.5.1.4.1.1.11.11​

Multiple Volume Rendering Volumetric Presentation State​Transfer​



Storage SOP Class​



1.2.840.10008.5.1.4.1.1.12.1​

X-Ray Angiographic Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.12.1.1​

Enhanced XA Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.12.2​

X-Ray Radiofluoroscopic Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.12.2.1​

Enhanced XRF Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.13.1.1​

X-Ray 3D Angiographic Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.13.1.2​

X-Ray 3D Craniofacial Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.13.1.3​

Breast Tomosynthesis Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.13.1.4​

Breast Projection X-Ray Image Storage - For Presentation​Transfer​



SOP Class​



1.2.840.10008.5.1.4.1.1.13.1.5​

Breast Projection X-Ray Image Storage - For Processing​Transfer​



SOP Class​



1.2.840.10008.5.1.4.1.1.14.1​

Intravascular Optical Coherence Tomography Image​

Transfer​



Storage - For Presentation SOP Class​



1.2.840.10008.5.1.4.1.1.14.2​

Intravascular Optical Coherence Tomography Image​

Transfer​



Storage - For Processing SOP Class​



1.2.840.10008.5.1.4.1.1.20​

Nuclear Medicine Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.30​

Parametric Map Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.66​

Raw Data Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.66.1​

Spatial Registration Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.66.2​

Spatial Fiducials Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.66.3​

Deformable Spatial Registration Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.66.4​

Segmentation Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.66.5​

Surface Segmentation Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.66.6​

Tractography Results Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.67​

Real World Value Mapping Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.68.1​

Surface Scan Mesh Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.68.2​

Surface Scan Point Cloud Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.77.1.1​

VL Endoscopic Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.77.1.1.1​

Video Endoscopic Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.77.1.2​

VL Microscopic Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.77.1.2.1​

Video Microscopic Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.77.1.3​

VL Slide-Coordinates Microscopic Image Storage SOP​

Transfer​



Class​



1.2.840.10008.5.1.4.1.1.77.1.4​

VL Photographic Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.77.1.4.1​

Video Photographic Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.77.1.5.1​

Ophthalmic Photography 8 Bit Image Storage SOP Class​Transfer​

1.2.840.10008.5.1.4.1.1.77.1.5.2​

OphthalmicPhotography16BitImageStorageSOPClass​Transfer​

1.2.840.10008.5.1.4.1.1.77.1.5.3​

Stereometric Relationship Storage SOP Class​

Transfer​

- Standard -​



DICOM PS3.2 2020a - Conformance​

Page 59​

UID Value​

UID Name​

Category​

1.2.840.10008.5.1.4.1.1.77.1.5.4​

Ophthalmic Tomography Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.77.1.5.5​

Wide Field Ophthalmic Photography Stereographic​

Transfer​



Projection Image Storage SOP Class​



1.2.840.10008.5.1.4.1.1.77.1.5.6​

WideFieldOphthalmicPhotography3DCoordinatesImage​Transfer​



Storage SOP Class​



1.2.840.10008.5.1.4.1.1.77.1.5.7​

OphthalmicOpticalCoherenceTomographyEnFaceImage​Transfer​



Storage SOP Class​



1.2.840.10008.5.1.4.1.1.77.1.5.8​

OphthalmicOpticalCoherenceTomographyB-scanVolume​Transfer​



Analysis Storage SOP Class​



1.2.840.10008.5.1.4.1.1.77.1.6​

VL Whole Slide Microscopy Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.78.1​

Lensometry Measurements Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.78.2​

Autorefraction Measurements Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.78.3​

Keratometry Measurements Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.78.4​

Subjective Refraction Measurements Storage SOP Class​Transfer​

1.2.840.10008.5.1.4.1.1.78.5​

Visual Acuity Measurements Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.78.6​

Spectacle Prescription Report Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.78.7​

Ophthalmic Axial Measurements Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.78.8​

Intraocular Lens Calculations Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.79.1​

Macular Grid Thickness and Volume Report Storage SOP​Transfer​



Class​



1.2.840.10008.5.1.4.1.1.80.1​

Ophthalmic Visual Field Static Perimetry Measurements​Transfer​



Storage SOP Class​



1.2.840.10008.5.1.4.1.1.81.1​

Ophthalmic Thickness Map Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.82.1​

Corneal Topography Map Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.88.11​

Basic Text SR Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.88.22​

Enhanced SR Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.88.33​

Comprehensive SR Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.88.34​

Comprehensive 3D SR Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.88.40​

Procedure Log Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.88.50​

Mammography CAD SR Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.88.59​

Key Object Selection Document Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.88.65​

Chest CAD SR Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.88.67​

X-Ray Radiation Dose SR Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.88.68​

Radiopharmaceutical Radiation Dose SR Storage SOP​ Transfer​



Class​



1.2.840.10008.5.1.4.1.1.88.69​

Colon CAD SR Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.88.70​

Implantation Plan SR Document Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.88.71​

Acquisition Context SR Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.88.72​

Simplified Adult Echo SR Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.88.73​

Patient Radiation Dose SR Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.88.74​

Planned Imaging Agent Administration SR Storage SOP​Transfer​



Class​



1.2.840.10008.5.1.4.1.1.88.75​

PerformedImagingAgentAdministrationSRStorageSOP​Transfer​



Class​



- Standard -​

Page 60​

DICOM PS3.2 2020a - Conformance​



UID Value​

UID Name​

Category​

1.2.840.10008.5.1.4.1.1.90.1​

Content Assessment Results Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.104.1​

Encapsulated PDF Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.104.2​

Encapsulated CDA Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.104.3​

Encapsulated STL Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.104.4​

Encapsulated OBJ Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.104.5​

Encapsulated MTL Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.128​

PositronEmissionTomographyImageStorageSOPClass​Transfer​

1.2.840.10008.5.1.4.1.1.130​

Enhanced PET Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.131​

Basic Structured Display Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.200.1​

CT Defined Procedure Protocol Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.200.2​

CT Performed Procedure Protocol Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.200.3​

Protocol Approval Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.481.1​

RT Image Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.481.2​

RT Dose Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.481.3​

RT Structure Set Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.481.4​

RT Beams Treatment Record Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.481.5​

RT Plan Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.481.6​

RT Brachy Treatment Record Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.481.7​

RT Treatment Summary Record Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.481.8​

RT Ion Plan Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.481.9​

RT Ion Beams Treatment Record Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.481.10​

RT Physician Intent Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.481.11​

RT Segment Annotation Storage SOP Class​

Transfer​

1.2.840.10008.5.1.4.1.1.481.12​

RT Radiation Set Storage​

Transfer​

1.2.840.10008.5.1.4.1.1.481.13​

C-Arm Photon-Electron Radiation Storage​

Transfer​

1.2.840.10008.5.1.4.1.1.481.14​

Tomotherapeutic Radiation Storage​

Transfer​

1.2.840.10008.5.1.4.1.1.481.15​

Robotic-Arm Radiation Storage​

Transfer​

1.2.840.10008.5.1.4.1.2.1.1​

PatientRootQuery/RetrieveInformationModel-FINDSOP​Query/Retrieve​



Class​



1.2.840.10008.5.1.4.1.2.1.2​

Patient Root Query/Retrieve Information Model - MOVE​ Query/Retrieve​



SOP Class​



1.2.840.10008.5.1.4.1.2.1.3​

PatientRootQuery/RetrieveInformationModel-GETSOP​Query/Retrieve​



Class​



1.2.840.10008.5.1.4.1.2.2.1​

StudyRootQuery/RetrieveInformationModel-FINDSOP​Query/Retrieve​



Class​



1.2.840.10008.5.1.4.1.2.2.2​

StudyRootQuery/RetrieveInformationModel-MOVESOP​Query/Retrieve​



Class​



1.2.840.10008.5.1.4.1.2.2.3​

Study Root Query/Retrieve Information Model - GET SOP​Query/Retrieve​



Class​



1.2.840.10008.5.1.4.1.2.4.2​

Composite Instance Root Retrieve - MOVE SOP Class​

Query/Retrieve​

1.2.840.10008.5.1.4.1.2.4.3​

Composite Instance Root Retrieve - GET SOP Class​

Query/Retrieve​

1.2.840.10008.5.1.4.1.2.5.3​

CompositeInstanceRetrieveWithoutBulkData-GETSOP​Query/Retrieve​



Class​



- Standard -​

Смотрите также:

«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
Значение, сущность и содержание социально — педагогической деятельности в организации для детей-сирот и детей, оставшихся без попечения родителей
__RGR2
__RGR2
_11_А. Франс для эл версии
_индив анализ данных
- Интерфейс 485 и оптопорт 11
:Конвергентный подход к проектированию дополнительных общеобразовательных общеразвивающих программ
