Page 26​ DICOM PS3.20 2020a - Imaging Reports using HL7 Clinical Document Architecture​

Table 5.2-1. Template table format​

ReferencedBusinessName​

5.2.1 Business Name​

This Part uses Business Names to identify and map common data elements from clinical imaging reports into the proper context-​ specific CDA/XML structure.​

A Business Name is assigned to each element or attribute that may have a user-specified value assigned in the production of the​ clinicaldocumentinstance.BusinessNamesarespecifiedtofacilitatetheimplementationofproductionlogicforclinicalreportauthoring​ applications. The benefit is that developers of clinical report authoring applications are not required to have an in depth knowledge​ of CDA, the HL7 v3 R-MIM data model, or the XML structures. The use of readable and intuitive Business Names provides a method​ of direct access to insert data that is specific to each clinical report instance.​

Note​

Business Names are also described in the HL7 greenCDAModules for CCD specification, but that specification implies the​ useofaspecificXMLstructureforproductionlogicthatisnotrequiredbythisPart.Thespecificationofproductionlogicusing​ Business Names is outside the scope of this Part.​

Business Names are not specified for elements that are expected to receive an automatically generated value, e.g., the id element​ for each document, section, and entry.​

As a convention, Business Names are represented in CamelCase (alternating upper and lower case, no spaces, initial letter in upper​ case) in the Business Name column of the template tables.​

Business Names are hierarchically organized, and contextually scoped by higher level Business Names.​

•​Data element/attribute level Business Names are shown in normal font​

•​Business Names that provide scoping for subsidiary Business Names are shown in bold font.​

•​Referenced Business Names from included templates are shown in italic (see Section 5.2.9)​

•​As a convention, hierarchical relationship between Business Names is shown with the : character.​

Scoping Business Names scope all attributes and elements subsidiary to the element to which the name is assigned.​

Examples:​

•​The top level scoping Business Name for an Imaging Report is "ImagingReport", and it scopes all attributes and elements in the​ document, i.e., including and subsidiary to the <ClinicalDocument> XML element​

•​TheBusinessNameforthe9.2ClinicalInformationreportsectionis"ImagingReport:ClinicalInformation",anditscopesallattributes​ and elements including and subsidiary to the <section> XML element in template 1.2.840.10008.9.2​

•​The Business Name for the text element of the 9.2 Clinical Information report section is "ImagingReport:ClinicalInformation:Text"​

•​The Business Name for the text element of the 9.6 Impression section is "ImagingReport:Impression:Text"​

Note that both 9.2 Clinical Information and 9.6 Impression define a Business Name "Text", but these are distinguished by their hier-​ archical location under the scoping Business Names of their respective sections.​

- Standard -​

5.2.1.1 Multiple Instantiations​

Some templates may be invoked multiple times in a document instance; for example, the 10.5 Quantity Measurement template is in-​ stantiated for each numeric measurement in a report. Each instantiation shall have an identifying string, unique within the document,​ usedasadiscriminatorbetweenthosemultipleinstantiations.TheBusinessNameforeachelementthatmayhavemultipleinstantiations​ hasasuffix[*],indicatingtheuseofadiscriminatorstring.ThisallowsBusinessNamebasedproductionlogicforauthoringapplications​ to identify specific instances of an element.​

Example 5.2.1.1-1. Example Business Name based production logic with discriminators for two​ measurements​

--"Q21a" is the discriminator for the first measurement

--"Q21b" is the discriminator for the second measurement ImagingReport:Findings:QuantityMeasurement[Q21a]:MeasurementName = ("112058", "DCM", "Calcium score") ImagingReport:Findings:QuantityMeasurement[Q21a]:MeasurementValue = "8" ImagingReport:Findings:QuantityMeasurement[Q21a]:MeasurementUnits = "[arb'U]" ImagingReport:Findings:QuantityMeasurement[Q21b]:MeasurementName = ("408716009", "SNOMED", "Stenotic lesion length") ImagingReport:Findings:QuantityMeasurement[Q21b]:MeasurementValue = "14" ImagingReport:Findings:QuantityMeasurement[Q21b]:MeasurementUnits = "mm"

ThediscriminatorstringshallbeconformanttoXMLNameproductionrequirements,asusedfortheXMLIDattribute(seeSection5.3.4​ on the use of XML ID).​

Some CDA elements may include an XML ID attribute. This attribute is identified by '*' (asterisk) as its Business Name, and its value​ shall be the discriminator string.​

5.2.1.2 Implicit Element Structure For Business Name​

A Business Name may be associated with an element subsidiary to another element that does not have an associated Business​ Name. In such a case, when the element with the Business Name is instantiated in a document, its entire parent element hierarchy​ must be instantiated, even if those elements are identified as optional.​

Note​

Forexample,inthe8.1GeneralHeadertemplate,ifRecipient:Nameisinstantiated,theentirehierarchicalstructureofinform-​ ationRecipient/intendedRecipient/informationRecipient/name must be instantiated to hold the name element content.​

5.2.2 Nesting Level​

CDA documents are encoded using the Extensible Markup Language (XML), and are marked up through hierarchically nested XML​ elements (tags). The Nesting Level column of the template tables identifies the hierarchical level of each element relative to the other​ elements in the table using the character right angle bracket '>'. Multiple levels of nesting are identified by multiple > characters.​

XML elements may have attributes, encoded as "<name>=<value>" pairs within the element tag. Such attributes are identified using​ the character at sign '@'.​

5.2.3 Element/Attribute Names and XPath Notation​

The name of each XML element and attribute used in a CDA document for which specific constraints are applied is shown in the​ Element/Attribute column of the template tables. Optional elements whose use is not specified nor constrained are not shown.​

Elements and attributes that use the default value specified in CDA Specification are not shown. For example, the Section element​ has default attributes classCode='DOCSECT' and moodCode='EVN'; these are not listed in the templates. In accordance with the​ HL7 v3 specification, attributes with default values need not be included in instances, and their absence implies the default value.​

XML Path Language (XPath) notation is used to identify the XML elements and attributes within the CDA document instance to which​ various constraints are applied. The implicit context of these expressions is the root node of the document, and traversing the path​

- Standard -​

to the root node of the relevant template. This notation provides a mechanism that will be familiar to developers for identifying parts​ of an XML document.​

XPath syntax selects nodes from an XML document using a path containing the context of the node(s). The path is constructed from​ node names and attribute names (prefixed by a '@') and concatenated with a '/' symbol.​

Example 5.2.3-1 is an example of a fragment of a CDA document.​

Example 5.2.3-1. XML document example​

<author>

<assignedAuthor>

...

<code codeSystem='2.16.840.1.113883.6.96' codeSystemName='SNOMED CT' code='17561000' displayName='Cardiologist' />

...

</assignedAuthor>

</author>

Table 5.2.3-1 is an example of a fragment of a template specification table.​

Table 5.2.3-1. Template element and attribute example​

InTable5.2.3-1,thecodeattributeofthecodeelementcouldbeselectedwiththeXPathexpressionauthor/assignedAuthor/code/@code.​

5.2.4 Cardinality​

Each element/attribute has a cardinality indicator that specifies the number of allowable occurrences within a template instance. The​ cardinality indicators are interpreted with the following format "m…n" where m represents the least and n the most:​

•​0..1 zero or one​

•​1..1 exactly one​

•​1..* at least one​

•​0..* zero or more​

•​1..n at least one and not more than n​

•​0..0 none [SHALL NOT]​

- Standard -​

5.2.5 Element/Attribute Conformance​

Each element/attribute has a conformance verb (keyword) in addition to the cardinality constraint.​

ThekeywordsSHALL,SHOULD,MAY,SHOULDNOT,SHALLNOT,andNEEDNOTinthisdocumentaretobeinterpretedasdescribed​ in ISO/IEC Directives, Part 2, Annex H "Verbal forms for the expression of provisions":​

•​SHALL: an absolute requirement​

•​SHALL NOT: an absolute prohibition against inclusion​

•​SHOULD/SHOULD NOT: a best practice or recommendation. There may be valid reasons to ignore a recommendation, but the​ full implications must be understood and carefully weighed before choosing to not adhere to the best practice.​

•​MAY/NEEDNOT:trulyoptional;canbeincludedoromittedatthediscretionofthecontentcreatorwithnoconformanceimplications​

The keyword SHALL is associated with a minimum cardinality of at least 1; other keywords have a minimum cardinality of 0. If an​ element is required by SHALL, but is not known (and would otherwise be omitted without the SHALL requirement), it must be repres-​ ented by a nullFlavor. SHALL allows the use of nullFlavor unless the requirement is on an attribute (nullFlavor does not apply to at-​ tributes), or the use of nullFlavor is explicitly precluded (see Section 5.2.7 Value Conformance and Section 5.3.2 Null Flavor).​

Within the template, the keyword COND (conditional) may be present. In this case, the specification of the condition, and the conform-​ ance verbs associated with the condition being true or false, are described below the table in a paragraph flagged with the COND​ keyword.​

In an open template, additional elements and attributes allowed by the CDA Specification are not precluded by template constraints,​ unless there are applicable SHALL NOT template specifications.​

5.2.6 Data Type​

The data type associated with each element/attribute is specified, as described in the CDA Specification and its referenced HL7v3​ Data Types Release 1. Elements that are simply tags with subsidiary content only of nested elements, e.g., RIM class clone names,​ have the Data Type column empty.​

Many data types are non-primitive, and may include constituent component elements and/or attributes. Such subsidiary components​ are not specified in the templates unless specific constraints are to be applied to them.​

5.2.7 Value Conformance​

Thetemplatetablemayconstrainvaluesorvocabulariestobeusedwithanelementorattribute.Valueconstraintsincludeaconformance​ verb (SHALL, SHOULD, MAY, etc.) as defined in Section 5.2.5, and specified in the Value Conformance column of the template​ tables.​

Elements for which nullFlavor is forbidden are indicated with an additional constraint keyword noNull.​

Additionally,constraintsspecifyingValueSetsincludeacodingstrengthconformanceCWE(CodedWithExtensibility)orCNE(Coded​ with No Extensibility), as defined in Core Principles and Properties of HL7 Version 3 Models, Release 1.​

Further, Value Set constraints can be static, meaning that they are bound to a specified version of a Value Set, or dynamic, meaning​ thattheyareboundtothemostcurrentversionoftheValueSet.Bydefault,ValueSetshavedynamicbinding,unlessexplicitlyspecified​ with an additional constraint keyword static.​

5.2.8 Value Specification​

The template table may constrain values to a single fixed value, to a Value Set from which the value is to be drawn, or to a named​ Concept Domain. It may non-normatively reference a mapping from a DICOM SOP Instance or an HL7 message.​

Thetemplatetablemaycontainelementswithoutavaluespecification,andwithoutaBusinessName.Thesearetypicallyidelements.​ The application creating the document instance shall fill these elements with appropriate values.​

- Standard -​

5.2.8.1 Coded Simple Value​

Values of Data Type CS (Coded Simple Value) have a fixed code system defined in the CDA Specification, and are simple strings.​ The template tables identify only the constraint on the code value, and do not specify the fixed code system nor the code meaning​ (display name), which are not encoded in the CDA instance.​

5.2.8.2 Concept Descriptor and Coded With Equivalents​

Single values of Data Type CD (Concept Descriptor) or CE (Coded With Equivalents) are specified in the template tables with the​ triplet notation specified in PS3.16:​

(CodeValue, Coding Scheme Designator, "Code Meaning")​

The Coding Scheme Designator is a simple human readable identifier of the code system, and corresponds to the optional​ codeSystemName attribute of the CD or CE element. The CDA Specification requires the Code System OID to be encoded in the​ codeSystem attribute of the CD or CE element. The corresponding OID for each Coding Scheme Designator is provided in Annex 8​ “Coding Schemes” in PS3.16. The Code Meaning is encoded in the displayName attribute of the CD or CE element.​

5.2.8.3 Value Set​

Elements whose value may be drawn from a Value Set will have that Value Set identified in the Value column introduced by the​ keyword ValueSet.​

5.2.8.4 Concept Domains​

Concept Domains (see definition in ) are used to provide a named category in a structural template that can be bound to a specific​ value or value set by an invoking template, thus specializing the structural template for a particular use case. Concept Domain names​ are introduced by the keyword ConceptDomain in the Value column. For example, the 10.5 Quantity Measurement template Concept​ Domain "observationType" might be bound to a value set of fetal ultrasound measurements in one invoking template, or to a value​ set of cardiac CT measurements in another invoking template.​

Concept Domain names are similar to element Business Names in that they provide a public interface that is bound to specific values​ laterinthedocumentspecificationandproductionprocess.ConceptDomainsdonothaveaValueConformanceverb;theconformance​ verb is specified when the Concept Domain is bound to a specific value or value set (see Section 5.2.9.1).​

5.2.8.5 Mapping From DICOM SOP Instances and HL7v2 Messages​

Elements whose value may be mapped from a DICOM SOP Instance or from an HL7v2 message have the source attribute name​ and tag identified in the Value column in italic font. Note that many of these values have their origin in IT systems outside the imaging​ department, and there may be alternate routes for these values to be accessed by the reporting application, e.g., from an HL7 FHIR​ web service.​

Note​

Due to differences in use of HL7v2 data elements, mappings should not be considered normative.​

Data mapped from a specific Attribute in the interpreted DICOM image(s) is identified by the Attribute Name and Tag, represented in​ the mapping as:​

Attribute Name (gggg,eeee)​

Data mapped from Attributes within sequences is identified with the > character:​

Sequence Attribute Name (ggg0,eee0) > Item Attribute Name (ggg1,eee1)​

Data mapped from an HL7v2 field in the order for the study is identified by the Element Name and Segment Field identifier:​

Element Name seg-n​
