DICOM PS3.3 2020a - Information Object Definitions​ Page 1691​

Table F.5-29. Registration Keys​

Key​

Tag​

Type​

Attribute Description​

Specific Character Set​

(0008,0005)​

1C​

Required if an extended or replacement​







character set is used in one of the keys.​

Content Date​

(0008,0023)​

1​

The date the content creation started.​

Content Time​

(0008,0033)​

1​

The time the content creation started.​

Include Table 10-12 “Content Identification Macro Attributes”​





Any other Attribute of the Spatial Registration IE Modules​

3​



Note​

BecauseReferencedSOPInstanceUIDinFile(0004,1511)maybeusedasa"pseudo"DirectoryRecordKey(seeTableF.3-​ 3), it is not duplicated in this list of keys.​

F.5.30 Fiducial Directory Record Definition​

The Directory Record is based on the specification of Section F.3. It is identified by a Directory Record Type of Value "FIDUCIAL."​ Table F.5-30 lists the set of keys with their associated Types for such a Directory Record Type. The description of these keys may​ be found in the Modules related to the Spatial Fiducials IE of Spatial Fiducials IOD. This Directory Record shall be used to reference​ a Spatial Fiducials SOP Instance. This type of Directory Record may reference a Lower-Level Directory Entity that includes one or​ more Directory Records as defined in Table F.4-1.​

Table F.5-30. Fiducial Keys​

Key​

Tag​

Type​

Attribute Description​

Specific Character Set​

(0008,0005)​

1C​

Required if an extended or replacement​







character set is used in one of the keys.​

Content Date​

(0008,0023)​

1​

The date the content creation started.​

Content Time​

(0008,0033)​

1​

The time the content creation started.​

Include Table 10-12 “Content Identification Macro Attributes”​





Any other Attribute of the Spatial Fiducials IE Modules​

3​



Note​

BecauseReferencedSOPInstanceUIDinFile(0004,1511)maybeusedasa"pseudo"DirectoryRecordKey(seeTableF.3-​ 3), it is not duplicated in this list of keys.​

F.5.31 Hanging Protocol Directory Record Definition​

The Directory Record is based on the specification of Section F.3. It is identified by a Directory Record Type of Value "HANGING​ PROTOCOL". Table F.5-31 lists the set of keys with their associated Types for such a Directory Record Type. The description of​ these keys may be found in the Modules related to the Hanging Protocol IOD. This Directory Record shall be used to reference a​ Hanging Protocol SOP Instance. This type of Directory Record may reference a Lower-Level Directory Entity that includes one or​ more Directory Records as defined in Table F.4-1.​

Table F.5-31. Hanging Protocol Keys​

Attribute Name​

Tag​

Type​

Attribute Description​

Specific Character Set​

(0008,0005)​

1C​

Required if an extended or replacement​







character set is used in one of the keys​

Hanging Protocol Name​

(0072,0002)​

1​



Hanging Protocol Description​

(0072,0004)​

1​



Hanging Protocol Level​

(0072,0006)​

1​



- Standard -​

Page 1692​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​



Tag​

Type​

Attribute Description​

Hanging Protocol Creator​



(0072,0008)​

1​



Hanging Protocol Creation DateTime​

(0072,000A)​

1​



HangingProtocolDefinitionSequence​

(0072,000C)​

1​

Sequence that defines the type of imaging​









StudiestowhichthisHangingProtocolapplies.​









One or more Items shall be included in this​









Sequence.​

>Modality​



(0008,0060)​

1C​

Required if Anatomic Region Sequence​









(0008,2218) is not present. May be present​









otherwise.​

>Anatomic Region Sequence​



(0008,2218)​

1C​

One or more Items shall be included in this​









Sequence.​









RequiredifModality(0008,0060)isnotpresent.​









May be present otherwise.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​





>Laterality​



(0020,0060)​

2C​

Required if Anatomic Region Sequence​









(0008,2218) is present.​

>Procedure Code Sequence​



(0008,1032)​

2​

Zero or more Items shall be included in this​









Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​





>Reason for Requested Procedure​



(0040,100A)​

2​

Zero or more Items shall be included in this​

Code Sequence​







Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​





Number of Priors Referenced​



(0072,0014)​

1​



Hanging Protocol User Identification​



(0072,000E)​

2​

Sequence that provides a coded identifier for​

Code Sequence​







the person, group, or site for which this​









Hanging Protocol was defined.​









Zero or one Item shall be included in this​









Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​





Any other Attribute of the Hanging Protocol IOD​

3​



Note​

BecauseReferencedSOPInstanceUIDinFile(0004,1511)maybeusedasa"pseudo"DirectoryRecordKey(seeTableF.3-​ 3), it is not duplicated in this list of keys.​

F.5.32 Encapsulated Document Directory Record Definition​

The Directory Record is based on the specification of Section F.3. It is identified by a Directory Record Type of Value "ENCAP DOC."​ Table F.5-32 lists the set of keys with their associated Types for such a Directory Record Type. The description of these keys may​ be found in the Modules related to the Encapsulated Document IE of Encapsulated IODs. This Directory Record shall be used to​ reference an Encapsulated Document SOP Instance. This type of Directory Record may reference a Lower-Level Directory Entity​ that includes one or more Directory Records as defined in Table F.4-1.​

Note​

Other Encapsulated Document SOP Classes may be added to the Standard in the future and these will likely be referenced​ by this directory record. Therefore, the MIME Type should be checked rather than assuming that the referenced file contains​ PDF.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​ Page 1693​

Table F.5-32. Encapsulated Document Keys​

Key​

Tag​

Type​

Attribute Description​

Specific Character Set​

(0008,0005)​

1C​

Required if an extended or replacement character set​







is used in one of the keys.​

Content Date​

(0008,0023)​

2​

The date the content creation started.​

Content Time​

(0008,0033)​

2​

The time the content creation started.​

Instance Number​

(0020,0013)​

1​

A number that identifies this instance​

Document Title​

(0042,0010)​

2​

The title of the document.​

HL7 Instance Identifier​

(0040,E001)​

1C​

Instance Identifier from the referenced HL7 Structured​







Document, encoded as a UID (OID or UUID),​







concatenated with a caret ("^") and Extension value (if​







Extension is present in Instance Identifier).​







RequiredifencapsulateddocumentisanHL7Structured​







Document.​

Concept Name Code Sequence​

(0040,A043)​

2​

A coded representation of the document title.​







Zero or one Item shall be included in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​



BCID 7020 “Document Titles”.​

MIME Type of Encapsulated​

(0042,0012)​

1​

The type of the encapsulated document stream​

Document​





describedusingtheMIMEMediaType(seeRFC2046).​

Any other Attribute of the Encapsulated Document Module​

3​



except Encapsulated Document (0042,0011)​





F.5.33 HL7 Structured Document Directory Record Definition​

Retired. See PS3.3 2018b.​

F.5.34 Real World Value Mapping Directory Record Definition​

The Directory Record is based on the specification of Section F.3. It is identified by a Directory Record Type of Value "VALUE MAP."​ Table F.5-34 lists the set of keys with their associated Types for such a Directory Record Type. The description of these keys may​ be found in the Modules related to the Real World Value Mapping IE of Real World Value Mapping IOD. This Directory Record shall​ beusedtoreferenceaRealWorldValueMappingSOPInstance.ThistypeofDirectoryRecordmayreferenceaLower-LevelDirectory​ Entity that includes one or more Directory Records as defined in Table F.4-1.​

Table F.5-34. Real World Value Mapping Keys​

Key​

Tag​

Type​

Attribute Description​

Specific Character Set​

(0008,0005)​

1C​

Required if an extended or replacement​







character set is used in one of the keys.​

Content Date​

(0008,0023)​

1​

The date the content creation started.​

Content Time​

(0008,0033)​

1​

The time the content creation started.​

Include Table 10-12 “Content Identification Macro Attributes”​





Any other Attribute of the Real World Value Mapping IE Modules​

3​



Note​

BecauseReferencedSOPInstanceUIDinFile(0004,1511)maybeusedasa"pseudo"DirectoryRecordKey(seeTableF.3-​ 3), it is not duplicated in this list of keys.​

- Standard -​

Page 1694​

DICOM PS3.3 2020a - Information Object Definitions​

F.5.35 Stereometric Relationship Directory Record Definition​

TheDirectoryRecordisbasedonthespecificationofSectionF.3.ItisidentifiedbyaDirectoryRecordTypeofValue"STEREOMETRIC".​ Table F.5-35 lists the set of keys with their associated Types for such a Directory Record Type. The description of these keys may​ be found in the Modules related to the Stereometric Relationship IE of Stereometric Relationship IOD. This Directory Record shall be​ used to reference a Stereometric Relationship SOP Instance. This type of Directory Record may reference a Lower-Level Directory​ Entity that includes one or more Directory Records as defined in Table F.4-1.​

Table F.5-35. Stereometric Relationship Keys​

Key​

Tag​

Type​

Attribute Description​

Specific Character Set​

(0008,0005)​

1C​

Required if an extended or replacement​







character set is used in one of the keys.​

Any other Attribute of the Stereometric Relationship IE Modules​

3​



Note​

BecauseReferencedSOPInstanceUIDinFile(0004,1511)maybeusedasa"pseudo"DirectoryRecordKey(seeTableF.3-​ 3), it is not duplicated in this list of keys.​

F.5.36 Palette Directory Record Definition​

The Directory Record is based on the specification of Section F.3. It is identified by a Directory Record Type of Value "PALETTE".​ Table F.5-36 lists the set of keys with their associated Types for such a Directory Record Type. The description of these keys may​ befoundintheModulesrelatedtotheColorPaletteIOD.ThisDirectoryRecordshallbeusedtoreferenceaColorPaletteSOPInstance.​ This type of Directory Record may reference a Lower-Level Directory Entity that includes one or more Directory Records as defined​ in Table F.4-1.​

Table F.5-36. Palette Keys​

Attribute Name​

Tag​

Type​

Attribute Description​

Specific Character Set​

(0008,0005)​

1C​

Requiredifanextendedorreplacementcharacter​







set is used in one of the keys​

Content Label​

(0070,0080)​

1​

A label that is used to identify the palette.​

Content Description​

(0070,0081)​

2​

A description of the content of the palette.​

Any other Attribute of the Color Palette IOD​

3​



Note​

BecauseReferencedSOPInstanceUIDinFile(0004,1511)maybeusedasa"pseudo"DirectoryRecordKey(seeTableF.3-​ 3), it is not duplicated in this list of keys.​

F.5.37 Implant Directory Record Definition​

The Directory Record is based on the specification of Section F.3. It is identified by a Directory Record Type of Value "IMPLANT".​ Table F.5-37 lists the set of keys with their associated Types for such a Directory Record Type. The description of these keys may​ be found in the Generic Implant Template IOD. This Directory Record shall be used to reference a Generic Implant Template SOP​ Instance.​

Table F.5-37. Implant Keys​

Key​

Tag​

Type​

Attribute Description​

Manufacturer​

(0008,0070)​

1​

Name of the manufacturer that produces the implant.​

Implant Name​

(0022,1095)​

1​

The (product) name of the implant.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 1695​

Key​

Tag​

Type​

Attribute Description​



Implant Size​

(0068,6210)​

1C​

The size descriptor of the component.​









Required if present in the referenced instance.​

Implant Part Number​

(0022,1097)​

1​

The (product) identifier of the implant.​



Note​

Because(0004,1511)ReferencedSOPInstanceUIDinFilemaybeusedasa"pseudo"DirectoryRecordKey(seeTableF.3-​ 3), it is not duplicated in this list of keys.​

F.5.38 Implant Assembly Directory Record Definition​

The Directory Record is based on the specification of Section F.3. It is identified by a Directory Record Type of Value "IMPLANT​ ASSY". Table F.5-38 lists the set of keys with their associated Types for such a Directory Record Type. The description of these keys​ maybefoundintheImplantAssemblyTemplateIOD.ThisDirectoryRecordshallbeusedtoreferenceanImplantAssemblyTemplate​ SOP Instance.​

Table F.5-38. Implant Assembly Keys​

Key​

Tag​

Type​

Attribute Description​

ImplantAssemblyTemplateName​

(0076,0001)​

1​

A name given to the assembly described in this​







instance.​

Manufacturer​

(0008,0070)​

1​

Nameofthemanufacturerthatproducestheimplant.​

Procedure Type Code Sequence​

(0076,0020)​

1​

A code describing the Intervention in which the​







implant is used.​

One or more Items shall be included in this​ Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

Note​

Because(0004,1511)ReferencedSOPInstanceUIDinFilemaybeusedasa"pseudo"DirectoryRecordKey(seeTableF.3-​ 3), it is not duplicated in this list of keys.​

F.5.39 Implant Group Directory Record Definition​

The Directory Record is based on the specification of Section F.3. It is identified by a Directory Record Type of Value "IMPLANT​ GROUP". Table F.5-39 lists the set of keys with their associated Types for such a Directory Record Type. The description of these​ keys may be found in the Implant Template Group IOD. This Directory Record shall be used to reference an Implant Template Group​ SOP Instance.​

Table F.5-39. Implant Group Keys​

Key​

Tag​

Type​

Attribute Description​

Implant Template Group Name​

(0078,0001)​

1​

Name of this group​

Implant Template Group Description​

(0078,0010)​

3​

Purpose or intent of this group.​

Implant Template Group Issuer​

(0078,0020)​

1​

PersonorOrganizationthatissuedthisgroup.​

Note​

Because(0004,1511)ReferencedSOPInstanceUIDinFilemaybeusedasa"pseudo"DirectoryRecordKey(seeTableF.3-​ 3), it is not duplicated in this list of keys.​

- Standard -​
