Page 1686​

DICOM PS3.3 2020a - Information Object Definitions​

Key​

Tag​

Type​

Attribute Description​

Presentation Creation Time​

(0070,0083)​

1​

Time at which this presentation was created.​







Note​







This time may be different from the time that the​







DICOM SOP Instance was created, since the​







presentation information contained may have been​







recorded earlier.​

Include Table 10-12 “Content Identification Macro Attributes”​



ReferencedSeriesSequence​

(0008,1115)​

1C​

Sequence of Items where each Item includes the Attributes of​







one Series to which the Presentation applies.​







One or more Items shall be included in this Sequence.​







Required if the IOD of the Presentation SOP Instance​







referenced by this directory record includes the Presentation​







State Relationship Module.​

>Series Instance UID​

(0020,000E)​

1​

Unique identifier of a Series that is part of this Study.​

>Referenced Image​

(0008,1140)​

1​

Sequence of Items where each Item provides reference to an​

Sequence​





Image SOP Instance.​







One or more Items shall be included in this Sequence.​

>>Include Table 10-11 “SOP Instance Reference Macro Attributes”​



Blending Sequence​

(0070,0402)​

1C​

Sequence of Items where each Item includes the Attributes of​







a Study to which the Presentation applies.​







Only two Items shall be included in this Sequence.​







RequirediftheSOPInstancereferencedbythisdirectoryrecord​







includes Blending Sequence (0070,0402).​

>Study Instance UID​

(0020,000D)​

1​

Unique identifier for a Study that contains the images to which​







the Presentation applies.​

>Referenced Series​

(0008,1115)​

1​

Sequence of Items where each Item includes the Attributes of​

Sequence​





one Series to which the Presentation applies.​







Only a single Item shall be included in this Sequence.​

>>Series Instance UID​

(0020,000E)​

1​

Unique identifier of the Series​

>>Referenced Image​

(0008,1140)​

1​

Sequence of Items where each Item provides reference to an​

Sequence​





Image SOP Instance to which the Presentation applies.​







One or more Items shall be included in this Sequence.​

>>>Include Table 10-11 “SOP Instance Reference Macro Attributes”​

Any other Attribute of the Presentation State IE​

3​



Modules​







Note​

BecauseReferencedSOPInstanceUIDinFile(0004,1511)maybeusedasa"pseudo"DirectoryRecordKey(seeTableF.3-​ 3), it is not duplicated in this list of keys.​

F.5.24 Waveform Directory Record Definition​

The Directory Record is based on the specification of Section F.3. It is identified by a Directory Record Type of Value "WAVEFORM".​ Table F.5-24 lists the set of keys with their associated Types for such a Directory Record Type. The description of these keys may​ befoundinPS3.3oftheDICOMStandardintheModulesrelatedtotheWaveformIE.ThisDirectoryRecordshallbeusedtoreference​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​

Page 1687​

a Waveform SOP Instance. This Type of Directory Record may reference a Lower-Level Directory Entity that includes one or more​ Directory Records as defined in Table F.4-1.​

Table F.5-24. Waveform Keys​

Key​

Tag​

Type​

Attribute Description​

Specific Character Set​

(0008,0005)​

1C​

Requiredifanextendedorreplacement​







character set is used in one of the keys.​

Instance Number​

(0020,0013)​

1​



Content Date​

(0008,0023)​

1​



Content Time​

(0008,0033)​

1​



Any other Attribute of the Waveform IE Modules​

3​



Note​

BecauseReferencedSOPInstanceUIDinFile(0004,1511)maybeusedasa"pseudo"DirectoryRecordKey(seeTableF.3-​ 3), it is not duplicated in this list of keys.​

F.5.25 SR Document Directory Record Definition​

TheDirectoryRecordisbasedonthespecificationofSectionF.3.ItisidentifiedbyaDirectoryRecordTypeofValue"SRDOCUMENT".​ Table F.5-25 lists the set of keys with their associated Types for such a Directory Record Type. The description of these keys may​ be found in the Modules related to the Observation IE of Structured Report IOD. This Directory Record shall be used to reference an​ SRDocument.ThistypeofDirectoryRecordmayreferenceaLower-LevelDirectoryEntitythatincludesoneormoreDirectoryRecords​ as defined in Table F.4-1.​

Table F.5-25. SR Document Keys​

Key​

Tag​

Type​

Attribute Description​

Specific Character Set​

(0008,0005)​

1C​

Required if an extended or replacement character set is​







used in one of the keys.​

Instance Number​

(0020,0013)​

1​



Completion Flag​

(0040,A491)​

1​



Verification Flag​

(0040,A493)​

1​



Content Date​

(0008,0023)​

1​



Content Time​

(0008,0033)​

1​



Verification DateTime​

(0040,A030)​

1C​

Most recent Date and Time of verification among those​







definedintheVerifyingObserverSequence(0040,A073).​







Required if Verification Flag (0040,A493) is VERIFIED.​

Concept Name Code​

(0040,A043)​

1​

Code describing the concept represented by the root​

Sequence​





Content Item (Document Title).​

Only a single Item shall be included in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

- Standard -​

Page 1688​

DICOM PS3.3 2020a - Information Object Definitions​

Key​

Tag​

Type​

Attribute Description​

Content Sequence​

(0040,A730)​

1C​

Contains the Target Content Items that modify the​







ConceptNameCodeSequenceoftherootContentItem​







(Document Title).​







One or more Items shall be included in this Sequence.​







All, and only, Content Items with the HAS CONCEPT​







MOD relationship from the root Content Item shall be​







included in this Sequence.​







Required if the root Content Item is the Source Content​







Item of HAS CONCEPT MOD relationships.​

>Relationship Type​

(0040,A010)​

1​

Enumerated Values:​







HAS CONCEPT MOD​

>Include Table C.17-5 “Document Content Macro Attributes”​





Any Attribute of the Document IE Modules​

3​



Note​

BecauseReferencedSOPInstanceUIDinFile(0004,1511)maybeusedasa"pseudo"DirectoryRecordKey(seeTableF.3-​ 3), it is not duplicated in this list of keys.​

F.5.26 Key Object Document Directory Record Definition​

The Directory Record is based on the specification of Section F.3. It is identified by a Directory Record Type of Value "KEY OBJECT​ DOC". Table F.5-25 lists the set of keys with their associated Types for such a Directory Record Type. The description of these keys​ may be found in the Modules related to the Document IE of the Key Object Selection IOD. This Directory Record shall be used to​ referenceaKeyObjectSelectionDocument.ThistypeofDirectoryRecordmayreferenceaLower-LevelDirectoryEntitythatincludes​ one or more Directory Records as defined in Table F.4-1.​

Table F.5-26. Key Object Document Keys​

Key​

Tag​

Type​

Attribute Description​

Specific Character Set​

(0008,0005)​

1C​

Required if an extended or replacement character set is​







used in one of the keys.​

Instance Number​

(0020,0013)​

1​



Content Date​

(0008,0023)​

1​



Content Time​

(0008,0033)​

1​



Concept Name Code​

(0040,A043)​

1​

Code describing the concept represented by the root​

Sequence​





Content Item (Document Title).​

Only a single Item shall be included in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 1689​

Key​

Tag​

Type​

Attribute Description​



Content Sequence​

(0040,A730)​

1C​

Contains the Target Content Items that modify the​







ConceptNameCodeSequenceoftherootContentItem​







(Document Title).​









One or more Items shall be included in this Sequence.​







All, and only, Content Items with the HAS CONCEPT​







MOD relationship from the root Content Item shall be​







included in this Sequence.​









Required if the root Content Item is the Source Content​







Item of HAS CONCEPT MOD relationships.​

>Relationship Type​

(0040,A010)​

1​

Enumerated Values:​









HAS CONCEPT MOD​



>Include Table C.17-5 “Document Content Macro Attributes”​







Any Attribute of the Document IE Modules​

3​





Note​

BecauseReferencedSOPInstanceUIDinFile(0004,1511)maybeusedasa"pseudo"DirectoryRecordKey(seeTableF.3-​ 3), it is not duplicated in this list of keys.​

F.5.27 Spectroscopy Directory Record Definition​

The Directory Record is based on the specification of Section F.3. It is identified by a Directory Record Type of Value "SPECTRO-​ SCOPY." Table F.5-27 lists the set of keys with their associated Types for such a Directory Record Type. The description of these​ keys may be found in the Modules related to the MR Spectroscopy IE of MR Spectroscopy IODs. This Directory Record shall be used​ to reference a Spectroscopy SOP Instance. This type of Directory Record may reference a Lower-Level Directory Entity that includes​ one or more Directory Records as defined in Table F.4-1.​

Table F.5-27. Spectroscopy Keys​

Key​

Tag​

Type​

Attribute Description​

Specific Character Set​

(0008,0005)​

1C​

Required if an extended or replacement​







character set is used in one of the keys.​

Image Type​

(0008,0008)​

1​



Content Date​

(0008,0023)​

1​



Content Time​

(0008,0033)​

1​



Instance Number​

(0020,0013)​

1​



Referenced Image Evidence​

(0008,9092)​

1C​

Required if present in the spectroscopy​

Sequence​





instance.​







One or more Items shall be included in​







this Sequence.​

>Include Table C.17-3 “Hierarchical SOP Instance Reference Macro Attributes”​



Number of Frames​

(0028,0008)​

1​



Rows​

(0028,0010)​

1​



Columns​

(0028,0011)​

1​



Data Point Rows​

(0028,9001)​

1​



Data Point Columns​

(0028,9002)​

1​



- Standard -​

Page 1690​

DICOM PS3.3 2020a - Information Object Definitions​

Key​

Tag​

Type​

Attribute Description​

Icon Image Sequence​

(0088,0200)​

3​

This Icon Image is representative of the​







Spectroscopy instance.​







Only a single Item is permitted in this​







Sequence.​

>Include Table C.7-11b “Image Pixel Macro Attributes”​



See Section F.7.​

Any other Attribute of the MR Spectroscopy IE Modules​

3​



Note​

BecauseReferencedSOPInstanceUIDinFile(0004,1511)maybeusedasa"pseudo"DirectoryRecordKey(seeTableF.3-​ 3), it is not duplicated in this list of keys.​

F.5.28 Raw Data Directory Record Definition​

The Directory Record is based on the specification of Section F.3. It is identified by a Directory Record Type of Value "RAW DATA."​ Table F.5-28 lists the set of keys with their associated Types for such a Directory Record Type. The description of these keys may​ be found in the Modules related to the Raw Data IE of Raw Data IODs. This Directory Record shall be used to reference a Raw Data​ SOPInstance.ThistypeofDirectoryRecordmayreferenceaLower-LevelDirectoryEntitythatincludesoneormoreDirectoryRecords​ as defined in Table F.4-1.​

Table F.5-28. Raw Data Keys​

Key​

Tag​

Type​

Attribute Description​

Specific Character Set​

(0008,0005)​

1C​

Required if an extended or replacement​







character set is used in one of the keys.​

Content Date​

(0008,0023)​

1​



Content Time​

(0008,0033)​

1​



Instance Number​

(0020,0013)​

2​



Icon Image Sequence​

(0088,0200)​

3​

This Icon Image is representative of the Raw​







Data instance.​







Only a single Item is permitted in this​







Sequence.​

>Include Table C.7-11b “Image Pixel Macro Attributes”​



See Section F.7.​

Any other Attribute of the Raw Data IE Modules​

3​



Note​

BecauseReferencedSOPInstanceUIDinFile(0004,1511)maybeusedasa"pseudo"DirectoryRecordKey(seeTableF.3-​ 3), it is not duplicated in this list of keys.​

F.5.29 Registration Directory Record Definition​

TheDirectoryRecordisbasedonthespecificationofSectionF.3.ItisidentifiedbyaDirectoryRecordTypeofValue"REGISTRATION."​ Table F.5-29 lists the set of keys with their associated Types for such a Directory Record Type. The description of these keys may​ be found in the Modules related to the Spatial Registration IE of the Spatial Registration IOD. This Directory Record shall be used to​ referenceaSpatialRegistrationSOPInstance.ThistypeofDirectoryRecordmayreferenceaLower-LevelDirectoryEntitythatincludes​ one or more Directory Records as defined in Table F.4-1.​

- Standard -​
