DICOM PS3.3 2020a - Information Object Definitions​

Page 1161​

•​TheAttributeReferencedInstanceSequence(0008,114A)isconveyedandonlyasingleItemisused.TheIteminReferencedInstance​ Sequence (0008,114A) contains the value "1.2.840.10008.5.1.4.1.1.78.7" = (this SOP Class) for Attribute Referenced SOP Class​ UID (0008,1150) and Attribute Referenced SOP Instance UID (0008,1155) will reference this measurement SOP Instance.​

•​Burned In Annotation (0028,0301) is set to NO.​

The Attribute Burned In Annotation (0028,0301) defines whether patient demographics have been burned into the image. This At-​ tribute does not prohibit non-demographic burned in annotation, such as position of gates, for image or waveform annotations that​ are very important to a user. Such annotations are expected to be conveyed and displayed.​

•​Quality Control Image (0028,0300) is set to YES.​

C.8.25.14.2 Ophthalmic Axial Length Segmental Measurements Macro​

Table C.8.25.14-3 describes the Attributes for the Ophthalmic Axial Length Segmental Measurements Macro.​

Table C.8.25.14-3. Ophthalmic Axial Length Segmental Measurements Macro Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Ophthalmic Axial Length​

(0022,1019)​

1​

The axial length measurement, in mm.​







The type of measurement is specified in the Ophthalmic​







Axial Length Measurements Type (0022,1010).​







SeeSectionC.8.25.14.1.1.3andSectionC.8.25.14.1.1.4​







for further explanation.​

Ophthalmic Axial Length​

(0022,1140)​

1​

Whether or not the clinician intervened to modify the​

Measurement Modified​





output of the device. For example by forcing it to select​







a different peak in the display.​







Enumerated Values:​







YES​







NO​

Ophthalmic Axial Length​

(0022,1101)​

1​

The name of the segment measured. See​

Measurements Segment Name​





Section C.8.25.14.1.1.4 for further explanation.​

Code Sequence​





Only a single Item shall be included in this Sequence.​







>Include Table 8.8-1 “Code Sequence Macro Attributes”​



DCID 4233 “Ophthalmic Axial Length Measurements​







Segment Names”​

Include Table C.8.25.14-4 “Ophthalmic Axial Measurements Related​

Information Macro Attributes”​

C.8.25.14.3 Ophthalmic Axial Measurements Related Information Macro​

Table C.8.25.14-4 describes the Attributes for the Ophthalmic Axial Measurements Related Information Macro.​

Table C.8.25.14-4. Ophthalmic Axial Measurements Related Information Macro Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Ultrasound Ophthalmic Axial​

(0022,1220)​

1C​

Relatedinformationaboutanaxiallengthmeasurementbeing​

Length Measurements Sequence​





performed on an ultrasound device.​







Only a single Item shall be included in this Sequence.​







Required if Ophthalmic Axial Measurements Device Type​







(0022,1009) is ULTRASOUND.​

- Standard -​

Page 1162​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

>Ophthalmic Axial Length Velocity​

(0022,1059)​

1​

The sound velocity used in calculating the Ophthalmic Axial​







Length Measurement Value (0022,1019), in m/sec.​

>Observer Type​

(0040,A084)​

1​

Method used to select which acquired axial length​







measurement values are kept.​







Enumerated Values:​







PSN​Person; manually selected​







DEV​Device; automatically selected​







See Section C.8.25.14.1.1.5 for further explanation.​

>Ophthalmic Axial Length Data​

(0022,1150)​

1​

Source of the value recorded in Ophthalmic Axial Length​

Source Code Sequence​





(0022,1019).​







Only a single Item shall be included in this Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​



DCID 4240 “Ophthalmic Measurement or Calculation Data​







Source”​

>Ophthalmic Axial Length Data​

(0022,1159)​

3​

A free text description of the axial length measurement data​

Source Description​





source.​

Optical Ophthalmic Axial Length​

(0022,1225)​

1C​

Relatedinformationaboutanaxiallengthmeasurementbeing​

Measurements Sequence​





performed on an optical device.​







Only a single Item shall be included in this Sequence.​







Required if Ophthalmic Axial Measurements Device Type​







(0022,1009) is OPTICAL.​

>Signal to Noise Ratio​

(0022,1155)​

3​

The ratio of signal power to the background noise power​







(Psignal / Pnoise).​

>Ophthalmic Axial Length Data​

(0022,1150)​

1​

The source of the value in Ophthalmic Axial Length​

Source Code Sequence​





(0022,1019).​







Only a single Item shall be included in this Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​



DCID 4240 “Ophthalmic Measurement or Calculation Data​







Source”​

>Ophthalmic Axial Length Data​

(0022,1159)​

3​

A free text description of the axial length measurement data​

Source Description​





source.​

C.8.25.14.4 Ophthalmic Axial Measurements Selected Macro​

Table C.8.25.14-5 describes the Attributes for the Ophthalmic Axial Measurements Selected Macro. These are the Attributes of the​ Ophthalmic Axial Length (0022,1019) selected for use in IOL calculations.​

Table C.8.25.14-5. Ophthalmic Axial Measurements Selected Macro Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

UltrasoundSelectedOphthalmic​

(0022,1230)​

1C​

Information related to the selected axial length measurement​

Axial Length Sequence​





of the patient's eye when acquired on an ultrasound device.​







Only a single Item shall be included in this Sequence.​







Required if Ophthalmic Axial Measurements Device Type​







(0022,1009) is ULTRASOUND.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 1163​

Attribute Name​

Tag​

Type​

Attribute Description​



>Ophthalmic Axial Length​

(0022,1010)​

3​

Identifies whether measuring the total axial length of the​

Measurements Type​





patient's eye or a segment of the eye for which a discrete​







measurement was obtained.​









Enumerated Values:​











TOTAL LENGTH​

the total axial length was taken with​









one measurement​









LENGTH​

the total axial length is a summation​







SUMMATION​

of segmental lengths​



>Ophthalmic Axial Length​

(0022,1019)​

1​

The axial length measurement, in mm.​









The type of measurement is specified in the Ophthalmic Axial​







Length Measurements Type (0022,1010).​









See Section C.8.25.14.1.1.4 for further explanation.​

>Ophthalmic Axial Length​

(0022,1250)​

1​

Method used to derive the value recorded in Ophthalmic Axial​

Selection Method Code​





Length (0022,1019).​





Sequence​





Only a single Item shall be included in this Sequence.​







>>Include Table 8.8-1 “Code Sequence Macro Attributes”. Defined​







CID 4241 “Ophthalmic Axial Length Selection Method”.​









>Referenced Ophthalmic Axial​

(0022,1330)​

1​

References to the quality control image associated with this​

LengthMeasurementQCImage​





measurement.​





Sequence​





Only a single Item shall be included in this Sequence.​













See Section C.8.25.14.1.1.6 for further explanation.​

>>IncludeTableC.8.25.16-6“OphthalmicAxialMeasurementsQuality​





Image SOP Instance Reference Macro Attributes”​









>Ophthalmic Axial Length​

(0022,1262)​

1​

Information about the quality metric applied to Ophthalmic​

Quality Metric Sequence​





Axial Length (0022,1019).​









Only a single Item shall be included in this Sequence.​

>>Include Table C.8.25.14-6 “Ophthalmic Axial Length Quality Metric​





Macro Attributes”​











>Selected Segmental​

(0022,1257)​

1C​

Segmental axial length measurements of a patient's eye that​

Ophthalmic Axial Length​





are summed to derive a total axial length for the eye.​

Sequence​





One or more Items shall be included in this Sequence.​













Required if the value of Ophthalmic Axial Length​







Measurements Type (0022,1010) is present and is LENGTH​







SUMMATION. May be present otherwise.​



>>Ophthalmic Axial Length​

(0022,1019)​

1​

The axial length measurement, in mm.​









The type of measurement is specified in the Ophthalmic Axial​







Length Measurements Type (0022,1010).​









See Section C.8.25.14.1.1.3 and Section C.8.25.14.1.1.4 for​







further explanation.​





>>Ophthalmic Axial Length​

(0022,1101)​

1​

Nameofthesegmentmeasured.SeeSectionC.8.25.14.1.1.4​

Measurements Segment Name​





for further explanation.​



Code Sequence​





Only a single Item shall be included in this Sequence.​







- Standard -​

Page 1164​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

>>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID4233“OphthalmicAxialLengthMeasurementsSegment​







Names”​



Optical Selected Ophthalmic​

(0022,1255)​

1C​

Informationrelatedtotheselectedaxiallengthmeasurement(s)​

Axial Length Sequence​





of the patient's eye when acquired on an optical device.​







One or more Items shall be included in this Sequence.​







Required if Ophthalmic Axial Measurements Device Type​







(0022,1009) is OPTICAL.​

>Ophthalmic Axial Length​

(0022,1010)​

3​

Identifies whether measuring the total axial length of the​

Measurements Type​





patient's eye or a segment of the eye for which a discrete​







measurement was obtained.​







Enumerated Values:​









TOTAL LENGTH​

the total axial length was taken with​









one measurement​







LENGTH​

the total axial length is a summation​







SUMMATION​

of segmental lengths​







SEGMENTAL​

the length of a segment of the axis​







LENGTH​



>Selected Total Ophthalmic​

(0022,1260)​

1C​

Total axial length measurement selected for the patient's eye.​

Axial Length Sequence​





Only a single Item shall be included in this Sequence.​













Required if the value of Ophthalmic Axial Length​







Measurements Type (0022,1010) is present and is either​







TOTAL LENGTH or LENGTH SUMMATION. May be present​







otherwise​









Note​









In case of Ophthalmic Axial Length Measurements​







Type (0022,1010) has the value LENGTH​







SUMMATION both the Selected Total Ophthalmic​







Axial Length Sequence (0022,1260) and Selected​







Segmental Ophthalmic Axial Length Sequence​







(0022,1257) are used.​

>>Ophthalmic Axial Length​

(0022,1019)​

1​

The axial length measurement, in mm.​







The type of measurement is specified in the Ophthalmic Axial​







Length Measurements Type (0022,1010).​







See Section C.8.25.14.1.1.3 and Section C.8.25.14.1.1.4 for​







further explanation.​



>>ReferencedOphthalmicAxial​

(0022,1330)​

1​

Reference to the quality control image associated with this​

LengthMeasurementQCImage​





measurement.​



Sequence​





Only a single Item shall be included in this Sequence.​













See Section C.8.25.14.1.1.6 for further explanation.​

>>>IncludeTableC.8.25.16-6“OphthalmicAxialMeasurementsQuality​



Image SOP Instance Reference Macro Attributes”​







>>Ophthalmic Axial Length​

(0022,1262)​

1​

Information about the quality metric applied to Ophthalmic​

Quality Metric Sequence​





Axial Length (0022,1019).​

Only a single Item shall be included in this Sequence.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 1165​

Attribute Name​

Tag​

Type​

Attribute Description​



>>>IncludeTableC.8.25.14-6“OphthalmicAxialLengthQualityMetric​



Macro Attributes”​









>Selected Segmental​

(0022,1257)​

1C​

Segmental axial length measurement(s) selected for the​

Ophthalmic Axial Length​





patient's eye.​



Sequence​





One or more Items shall be included in this Sequence.​













Required if the value of Ophthalmic Axial Length​







Measurements Type (0022,1010) is present and is either​







SEGMENTAL LENGTH or LENGTH SUMMATION. May be​







present otherwise.​









Note​









In case of Ophthalmic Axial Length Measurements​







Type (0022,1010) has the value LENGTH​









SUMMATION both the Selected Total Ophthalmic​







Axial Length Sequence (0022,1260) and Selected​







Segmental Ophthalmic Axial Length Sequence​







(0022,1257) are used.​



>>Ophthalmic Axial Length​

(0022,1101)​

1​

Nameofthesegmentmeasured.SeeSectionC.8.25.14.1.1.4​

Measurements Segment Name​





for further explanation.​



Code Sequence​





Only a single Item shall be included in this Sequence.​







>>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID4233“OphthalmicAxialLengthMeasurementsSegment​







Names”​



>>Ophthalmic Axial Length​

(0022,1019)​

1​

The axial length measurement, in mm.​









The type of measurement is specified in the Ophthalmic Axial​







Length Measurements Type (0022,1010).​









See Section C.8.25.14.1.1.3 and Section C.8.25.14.1.1.4 for​







further explanation.​



>>ReferencedOphthalmicAxial​

(0022,1330)​

3​

Reference to the quality control image associated with this​

LengthMeasurementQCImage​





measurement.​



Sequence​





Only a single Item is permitted in this Sequence.​













See Section C.8.25.14.1.1.6 for further explanation.​

>>>IncludeTableC.8.25.16-6“OphthalmicAxialMeasurementsQuality​



Image SOP Instance Reference Macro Attributes”​







>>Ophthalmic Axial Length​

(0022,1262)​

3​

Information about the quality metric applied to Ophthalmic​

Quality Metric Sequence​





Axial Length (0022,1019).​



Only a single Item is permitted in this Sequence.​

>>>IncludeTableC.8.25.14-6“OphthalmicAxialLengthQualityMetric​ Macro Attributes”​

C.8.25.14.5 Ophthalmic Axial Measurements Quality Metric Macro​

Table C.8.25.14-6 describes the Attributes for the Ophthalmic Axial Length Quality Metric Macro.​

- Standard -​

Смотрите также:

«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
Значение, сущность и содержание социально — педагогической деятельности в организации для детей-сирот и детей, оставшихся без попечения родителей
__RGR2
__RGR2
_11_А. Франс для эл версии
_индив анализ данных
- Интерфейс 485 и оптопорт 11
:Конвергентный подход к проектированию дополнительных общеобразовательных общеразвивающих программ
