DICOM PS3.3 2020a - Information Object Definitions​ Page 631​

Table C.8.2.2-4. Multi-energy CT Path Macro Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Multi-energyCTPathSequence​

(0018,9379)​

1​ Describes the paths corresponding to each energy level of a​







Multi-energy acquisition. Each path consists of a source (see​







Section C.8.2.1.1.1) and a detector (see Section C.8.2.2.1.1).​







Two or more Items shall be included in this Sequence.​







See also Section C.8.2.2.1 and Section C.8.2.2.2.​

>Multi-energy CT Path Index​

(0018,937A)​

1​ Identification number of the element in the Multi-energy CT Path​







Sequence.​







The number shall be 1 for the first Item and increase by 1 for each​







subsequent Item.​

>Referenced X-Ray Source​

(0018,9377)​

1​ References the X-Ray Source Index (0018,9366) in the Multi-energy​

Index​





CT X-Ray Source Sequence (0018,9365) in this path.​

>Referenced X-Ray Detector​

(0018,9376)​

1​ ReferencestheX-RayDetectorIndex(0018,9370)intheMulti-energy​

Index​





CT X-Ray Detector Sequence (0018,936F) in this path.​

C.8.3 MR Modules​

This Section describes the MR Image Module. This Module contains all Attributes that are specific to MR images.​

C.8.3.1 MR Image Module​

Table C.8-4 contains the Attributes that describe MR images.​

Table C.8-4. MR Image Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Image Type​

(0008,0008)​

1​ Image identification characteristics. See Section C.8.3.1.1.1 for​







specialization.​

Samples per Pixel​

(0028,0002)​

1​ Number of samples (planes) in this image. See Section C.8.3.1.1.2​







for specialization.​

Photometric Interpretation​

(0028,0004)​

1​ Specifies the intended interpretation of the pixel data. See​







Section C.8.3.1.1.3 for specialization.​

Bits Allocated​

(0028,0100)​

1​ Number of bits allocated for each pixel sample. Each sample shall​







have the same number of bits allocated. See Section C.8.3.1.1.4 for​







specialization.​

Bits Stored​

(0028,0101)​

1​ Numberofbitsstoredforeachpixelsample.Eachsampleshallhave​







the same number of bits stored.​

High Bit​

(0028,0102)​

1​ Most significant bit for pixel sample data. Each sample shall have​







the same high bit. High Bit (0028,0102) shall be one less than Bits​







Stored (0028,0101).​

- Standard -​

Page 632​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​



Attribute Description​

Scanning Sequence​

(0018,0020)​

1​

Description of the type of data taken.​







Enumerated Values:​







SE​Spin Echo​







IR​Inversion Recovery​







GR​Gradient Recalled​







EP​Echo Planar​







RM​Research Mode​







Note​







Multi-valued,butnotallcombinationsarevalid(e.g.,SE/GR,​







etc.).​

Sequence Variant​

(0018,0021)​

1​

Variant of the Scanning Sequence.​







Defined Terms:​







SK​

segmented k-space​







MTC​ magnetization transfer contrast​







SS​

steady state​







TRSS​time reversed steady state​







SP​

spoiled​







MP​

MAG prepared​







OSP​ oversampling phase​







NONE​no sequence variant​

Scan Options​

(0018,0022)​

2​

Parameters of scanning sequence.​







Defined Terms:​







PER​Phase Encode Reordering​







RG​ Respiratory Gating​







CG​ Cardiac Gating​







PPG​Peripheral Pulse Gating​







FC​ Flow Compensation​







PFF​Partial Fourier - Frequency​







PFP​Partial Fourier - Phase​







SP​ Spatial Presaturation​







FS​ Fat Saturation​

MR Acquisition Type​

(0018,0023)​

2​

Identification of data encoding scheme.​







Enumerated Values:​







2D​frequency x phase​







3D​frequency x phase x phase​

Repetition Time​

(0018,0080)​

2C​

The period of time in msec between the beginning of a pulse​







sequenceandthebeginningofthesucceeding(essentiallyidentical)​







pulse sequence.​







Required if Sequence Variant (0018,0021) is SK or if Scanning​







Sequence (0018,0020) is not EP. May be present otherwise.​

Echo Time​

(0018,0081)​

2​

Time in ms between the middle of the excitation pulse and the peak​







of the echo produced (kx=0). In the case of segmented k-space, the​







TE(eff) is the time between the middle of the excitation pulse to the​







peak of the echo that is used to cover the center of k-space (i.e.,​







-kx=0, ky=0).​

Echo Train Length​

(0018,0091)​

2​

Number of lines in k-space acquired per excitation per image.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 633​

Attribute Name​

Tag​

Type​

Attribute Description​



Inversion Time​

(0018,0082)​

2C​

Time in msec after the middle of inverting RF pulse to middle of​







excitation pulse to detect the amount of longitudinal magnetization.​







Required if Scanning Sequence (0018,0020) has values of IR.​

Trigger Time​

(0018,1060)​

2C​

Time, in msec, between peak of the R wave and the peak of the​







echoproduced.Inthecaseofsegmentedk-space,theTE(eff)isthe​







time between the peak of the echo that is used to cover the center​







ofk-space.RequiredforScanOptions(0018,0022)thatincludeheart​







gating (e.g., CG, PPG, etc.)​



Sequence Name​

(0018,0024)​

3​

User defined name for the combination of Scanning Sequence​







(0018,0020) and Sequence Variant (0018,0021).​



Angio Flag​

(0018,0025)​

3​

Angio Image Indicator. Primary image for Angio processing.​







Enumerated Values:​









Y​Image is Angio​









N​Image is not Angio​



Number of Averages​

(0018,0083)​

3​

Number of times a given pulse sequence is repeated before any​







parameter is changed​



Imaging Frequency​

(0018,0084)​

3​

Precession frequency in MHz of the nucleus being addressed​

Imaged Nucleus​

(0018,0085)​

3​

Nucleus that is resonant at the imaging frequency. Examples: 31P,​







1H​



Echo Number(s)​

(0018,0086)​

3​

The echo number used in generating this image. In the case of​







segmented k-space, it is the effective Echo Number.​



Magnetic Field Strength​

(0018,0087)​

3​

Nominal field strength of MR magnet, in Tesla​



Spacing Between Slices​

(0018,0088)​

3​

Spacing between slices, in mm. The spacing is measured from the​







center-to-center of each slice.​



NumberofPhaseEncoding​

(0018,0089)​

3​

Total number of lines in k-space in the 'y' direction collected during​

Steps​





acquisition.​



Percent Sampling​

(0018,0093)​

3​

Fractionofacquisitionmatrixlinesacquired,expressedasapercent.​

Percent Phase Field of​

(0018,0094)​

3​

Ratio of field of view dimension in phase direction to field of view​

View​





dimension in frequency direction, expressed as a percent.​

Pixel Bandwidth​

(0018,0095)​

3​

Reciprocal of the total sampling period, in hertz per pixel.​

Nominal Interval​

(0018,1062)​

3​

Average R-R interval used for the scans, in msec​



Beat Rejection Flag​

(0018,1080)​

3​

Beat length sorting has been applied.​









Enumerated Values:​









Y​yes​









N​no​



Low R-R Value​

(0018,1081)​

3​

R-R interval low limit for beat rejection, in msec​



High R-R Value​

(0018,1082)​

3​

R-R interval high limit for beat rejection, in msec​



Intervals Acquired​

(0018,1083)​

3​

Number of R-R intervals acquired.​



Intervals Rejected​

(0018,1084)​

3​

Number of R-R intervals rejected.​



PVC Rejection​

(0018,1085)​

3​

Description of type of PVC rejection criteria used.​



Skip Beats​

(0018,1086)​

3​

Number of beats skipped after a detected arrhythmia.​



Heart Rate​

(0018,1088)​

3​

Beats per minute.​



Cardiac Number of Images​

(0018,1090)​

3​

Number of images per cardiac cycle.​



Trigger Window​

(0018,1094)​

3​

PercentofR-Rinterval,basedonHeartRate(0018,1088),prescribed​







as a window for a valid/usable trigger.​



- Standard -​

Page 634​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Reconstruction Diameter​

(0018,1100)​

3​ Diameter in mm. of the region from within which data were used in​







creatingthereconstructionoftheimage.Datamayexistoutsidethis​







region and portions of the patient may exist outside this region.​







Thediameterdefinesacircularregionthatisentirelycontainedwithin​







the encoded Pixel Data (7FE0,0010), unless the encoded image​







has been cropped after reconstruction.​







Note​







If not cropped or padded, for square images with square​







pixels, both values of Pixel Spacing (0028,0030) will be​







equal and equal to Reconstruction Diameter (0018,1100)​







/ Rows (0028,0010) and Reconstruction Diameter​







(0018,1100) / Columns (0028,0011).​

Receive Coil Name​

(0018,1250)​

3​

Receive coil used.​

Transmit Coil Name​

(0018,1251)​

3​

Transmit coil used.​

Acquisition Matrix​

(0018,1310)​

3​ Dimensions of the acquired frequency /phase data before​







reconstruction.​







Multi-valued:frequencyrows\frequencycolumns\phaserows\phase​







columns.​

In-plane Phase Encoding​

(0018,1312)​

3​ The axis of phase encoding with respect to the image.​

Direction​





Enumerated Values:​













ROW​phase encoded in rows.​







COL​phase encoded in columns.​

Flip Angle​

(0018,1314)​

3​ Steadystateangleindegreestowhichthemagneticvectorisflipped​







from the magnetic vector of the primary field.​

SAR​

(0018,1316)​

3​ Calculated whole body Specific Absorption Rate in watts/kilogram.​

Variable Flip Angle Flag​

(0018,1315)​

3​ Flip angle variation applied during image acquisition.​







Enumerated Values:​







Y​yes​







N​no​

dB/dt​

(0018,1318)​

3​ The rate of change of the gradient coil magnetic flux density with​







time (T/s).​

TemporalPositionIdentifier​

(0020,0100)​

3​ Temporal order of a dynamic or functional set of Images.​

Number of Temporal​

(0020,0105)​

3​ Total number of temporal positions prescribed.​

Positions​







Temporal Resolution​

(0020,0110)​

3​ TimedeltabetweenImagesinadynamicorfunctionalsetofImages.​

IncludeTable10-7“GeneralAnatomyOptionalMacroAttributes”​Defined CID for the Anatomic Region Sequence is CID 4030 “CT,​ MR and PET Anatomy Imaged”.​

Include Table 10-25 “Optional View and Slice Progression​

Direction Macro Attributes”​

Isocenter Position​ (300A,012C)​ 3​ Isocenter coordinates (x,y,z), in mm. Specifies the location of the​ machine isocenter in the Patient-Based Coordinate System​ associated with the Frame of Reference. It allows transformation​ fromtheEquipment-BasedCoordinateSystemtothePatient-Based​ Coordinate System.​

- Standard -​



DICOM PS3.3 2020a

- Information Object Definitions​

Page 635​

Attribute Name​

Tag​

Type​

Attribute Description​



B1rms​

(0018,1320)​

3​



B1+ rms value in units of micro_tesla (uT) for the acquisition​









producing the image. See [IEC 60601-2-33].​



C.8.3.1.1 MR Image Attribute Descriptions​

C.8.3.1.1.1 Image Type​

For MR Images, Image Type (0008,0008) is specified to be Type 1.​

Defined Terms for Value 3:​

DENSITY MAP​

DIFFUSION MAP​

IMAGE ADDITION​

MODULUS​

SUBTRACT​

MPR​

OTHER​

PHASE MAP​

PHASE SUBTRACT​

PROJECTIONIMAGE​

T1 MAP​

T2 MAP​

VELOCITY MAP​

C.8.3.1.1.2 Samples Per Pixel​

Enumerated Values:​

1​

C.8.3.1.1.3 Photometric Interpretation​

Enumerated Values:​

MONOCHROME1​

MONOCHROME2​

See Section C.7.6.3.1.2 for definition of these terms.​

C.8.3.1.1.4 Bits Allocated​

Enumerated Values:​

16​

C.8.4 Nuclear Medicine Modules​

This Section describes Nuclear Medicine Series, Equipment, and Image Modules. These Modules contain Attributes that are specific​ to the NM Image IOD.​

Note​

There are some cases where it may be necessary to use several SOP Instances to encode a single NM acquisition. For​ example, the matrix size must remain constant within a SOP instance. Multiple matrix sizes require multiple SOP instances.​ Similarly, multiple gated stress levels require separate SOP instances for each stress level. However, a receiving AE is not​ expected to recombine them.​

C.8.4.1 NM Series Module (Retired)​

This Section was defined in a previous version of the DICOM Standard. The Section is now retired.​

- Standard -​

Смотрите также:

«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
Значение, сущность и содержание социально — педагогической деятельности в организации для детей-сирот и детей, оставшихся без попечения родителей
__RGR2
__RGR2
_11_А. Франс для эл версии
_индив анализ данных
- Интерфейс 485 и оптопорт 11
:Конвергентный подход к проектированию дополнительных общеобразовательных общеразвивающих программ
