Common MODBUS functions • 287

Function code FC5 (Write Coil)

6.2.5Function code FC5 (Write Coil)

With the aid of this function a single output bit is written.

Request

The request determines the address of the output bit. Addressing starts with 0. Example: The second output bit is set (address 1):

Byte

Field name

Example

Byte 0, 1

Transaction identifier

0x0000







Byte 2, 3

protocol identifier

0x0000







Byte 4, 5

length field

0x0006







Byte 6

unit identifier

0x01 not used







Byte 7

MODBUS function code

0x05







Byte 8, 9

reference number

0x0001







Byte 10

ON/OFF

0xFF







Byte 11



0x00







Response





Byte

Field name

Example

.....











Byte 7

MODBUS function code

0x05







Byte 8, 9

Reference number

0x0001







Byte 10

Value

0xFF







Byte 11



0x00







Exception





Byte

Field name

Example

.....











Byte 7

MODBUS function code

0x85







Byte 8

Exception code

0x01, 0x02 or 0x03







Modular I/O System

ETHERNET TCP/IP

288 • Common MODBUS functions Function code FC6 (Write single register)

6.2.6Function code FC6 (Write single register)

This function writes a value in one single output word (also ”Output register”).

Request

Addressing starts with 0. The inquiry determines the address of the first output word to be set. The value to be set is determined in the inquiry data field.

Example: The second output (address 0) is set to the value 0x1234.

Byte

Field name

Example

Byte 0, 1

Transaction identifier

0x0000







Byte 2, 3

protocol identifier

0x0000







Byte 4, 5

length field

0x0006







Byte 6

Unit identifier

0x01 not used







Byte 7

MODBUS function code

0x06







Byte 8, 9

reference number

0x0001







Byte 10, 11

Register Value

0x1234







Response

The reply is an echo of the inquiry.

Byte

Field name

Example

.....











Byte 7

MODBUS function code

0x06







Byte 8, 9

Reference number

0x0001







Byte 10, 11

Register Value

0x1234







Exception





Byte

Feldname

Example

.....











Byte 7

MODBUS function code

0x85







Byte 8

Exception code

0x01 or 0x02







Modular I/O System

ETHERNET TCP/IP

Common MODBUS functions • 289

Function code FC7 (Read Exception Status)

6.2.7Function code FC7 (Read Exception Status)

This function reads the first 8 bits of the process output image.

Request











Byte

Field name

Example

Byte 0, 1

Transaction identifier

0x0000







Byte 2, 3

protocol identifier

0x0000







Byte 4, 5

length field

0x0002







Byte 6

unit identifier

0x01 not used







Byte 7

MODBUS function code

0x07







Response





Byte

Field name

Example

...











Byte 7

MODBUS function code

0x07







Byte 8

Reference number

0x00







Exception





Byte

Field name

Example

...











Byte 7

MODBUS function code

0x85







Byte 8

Exception code

0x01 or 0x02







Modular I/O System

ETHERNET TCP/IP

290 • Common MODBUS functions Function code FC15 (Force Multiple Coils)

6.2.8Function code FC15 (Force Multiple Coils)

Using this function a number of output bits are set to 1 or 0. The maximum number is 256 bits.

Request

The first point is addressed with 0.

The inquiry message specifies the bits to be set. The requested 1 or 0 states are determined by the contents of the inquiry data field.

In this example 16 bits are set, starting with the address 0. The inquiry contains 2 bytes with the value 0xA5F0 or 1010 0101 1111 0000 in binary format.

The first byte transmits the 0xA5 to the addresses 7 to 0, whereby 0 is the lowest value bit. The next byte transmits 0xF0 to the addresses 15 to 8, whereby the lowest value bit is 8.

Byte

Field name

Example

Byte 0, 1

Transaction identifier

0x0000







Byte 2, 3

protocol identifier

0x0000







Byte 4, 5

Length field

0x0009







Byte 6

unit identifier

0x01 not used







Byte 7

MODBUS function code

0x0F







Byte 8, 9

reference number

0x0000







Byte 10, 11

Bit Count

0x0010







Byte 12

Byte Count

0x02







Byte 13

Data Byte1

0xA5







Byte 14

Data Byte2

0xF0







Response











Byte

Field name

Example

.....











Byte 7

MODBUS function code

0x0F







Byte 8, 9

Reference number

0x0000







Byte 10, 11

Bit Count

0x0010







Exception











Byte

Field name

Example

.....











Byte 7

MODBUS function code

0x8F







Byte 8

Exception code

0x01 or 0x02







Modular I/O System

ETHERNET TCP/IP

Common MODBUS functions • 291

Function code FC16 (Write multiple registers)

6.2.9Function code FC16 (Write multiple registers)

This function writes values in a number of output words (also ”Output register”).

Request

The first point is addressed with 0.

The inquiry message determines the registers to be set. The data is sent as 2 bytes per register.

The example shows how data is set in the two registers 0 and 1:

Byte

Field name

Example

Byte 0, 1

Transaction identifier

0x0000







Byte 2, 3

protocol identifier

0x0000







Byte 4, 5

length field

0x000B







Byte 6

Unit identifier

0x01 not used







Byte 7

MODBUS function code

0x10







Byte 8, 9

reference number

0x0000







Byte 10, 11

Word count

0x0002







Byte 12

Byte Count

0x04







Byte 13, 14

Register Value 1

0x1234







Byte 15, 16

Register Value 2

0x2345







Response





Byte

Field name

Example

.....











Byte 7

MODBUS function code

0x10







Byte 8, 9

Reference number

0x0000







Byte 10, 11

Register Value

0x0002







Exception





Byte

Field name

Example

.....











Byte 7

MODBUS function code

0x85







Byte 8

Exception code

0x01 or 0x02







Modular I/O System

ETHERNET TCP/IP
