WUHAN FANSO TECHNOLOGY CO.,LTD.

soldering irons within 5 seconds. 5

7.Short-circuits through Piled Circuit Boards

When circuit boards with the batteries are piled on top of one another, their conductive traces may touch and form a battery discharge circuit that consumes the battery's power.

电池能量

8.Discharge through Conductive Electrostatic Prevention Mats

Conductive mats are widely used to prevent static electricity from destroying semiconductors. If a circuit board with mounted battery is put on a conductive mat, the soldered conductors may touch the mat, providing a discharge path for the battery.

9.Improper Battery Mounting Polarity

When the battery's positive (+)and negative (-)terminals are reversed with respect to the battery mounting's polarity marks, the battery may be discharged, depending on the type of electric circuit. (+) (-)

10.Solder

When the battery lead plates are dipped in a molten solder bath, the battery is temporarily short-circuited. Therefore, complete dipping within 5 seconds.

5

●Handling Precautions

Please read and observe the follwing precautions thoroughly.

Lithium Manganese Dioxide Battery contains flammable materials, such as organis solvent. Improper battery handling may cause leakage, heating, explosion or ignition of the battery,

which may lead to injury or product failure. ) ( -

WARNING

(1)Never charge the battery. Charging the battery may cause seethe of the battery electrolyte or increase of the battery internal pressure. Leakage, heating, explosion or ignition of the battery

may be caused as a result of it.

(2)Keep away from infants. If infant happens to swallow the battery, consult a doctor Immediately.

(3)In case of eye contact with the battery electrolyte, immediately flush eyes thoroughly with water, and consult a doctor.

(4)In case the battery electrolyte happen to come into mouth, gargle well enough and consult a doctor immediately.

(5)Do not heat or disposed in fire or water. Do not modify or disassemble the battery. It may damage the gasket, and may cause ignition, heating, leakage or explosion.

- 16 -

WUHAN FANSO TECHNOLOGY CO.,LTD.

(6)Do not short-circuit positive (+) and negative (-) terminals. Keep away from metal or other conductive materials. Jumbling the batteries of direct contact with positive (+) and negative (-) terminals and metal or other conductive materials may cause short.

(+) (-)

(+) (-)

(7)When the battery is stored or disposed, isolate positive (+) and negative (-) terminals of the battery to avoid those terminals touch each other.

(+) (-)

(8)Insert the battery with positive (+) and negative (-) terminals correctly oriented.

(+) (-)

PRECAUTIONS

(1)Do not put the battery into microwave over or drying machine.

(2)Do not drop, apply excessive damage or deform the battery.

(3)Do not mix the used battery together with the new battery or different type of batteries.

(4)Do not store the battery in high temperature and high humidity location and where the battery is exposed to sunlight to avoid performance deterioration, swelling or leakage, of the battery.

液
