SoftMotion: DriveInterface: Bosch Rexroth SercansII PCI
Document Version 1.03
tech_doc_e.doc / V1.1
© 3S - Smart Software Solutions GmbH |
Page 1 of 9 |
SercansII_E.doc |
|
SoftMotion: DriveInterface: Bosch Rexroth SercansII PCI
CONTENT |
|
|
1 |
FILES |
3 |
2 |
JOB STEPS |
4 |
3 |
PRECONDITIONS AND KNOWN LIMITATIONS |
5 |
4 |
REFERENCED LIBRARIES |
6 |
5 |
CONFIGURATION |
7 |
6 |
DETECT AND SOLVE PROBLEMS |
8 |
CHANGE HISTORY |
9 |
|
This document describes the steps to do, if you want to use the Bosch Rexroth SercansII PCI card together with CoDeSys SP RTE or CoDeSys SP 32 bit full.
tech_doc_e.doc / V1.1
© 3S - Smart Software Solutions GmbH |
Page 2 of 9 |
SercansII_E.doc |
|
SoftMotion: DriveInterface: Bosch Rexroth SercansII PCI
1 Files
This driver consists of:
SercansII.lib |
CoDeSys library |
|
|
SercansII_E.pdf |
This document |
|
|
RTIOdrvBRCSerc.sys |
Driver for CoDeSys SP RTE |
|
|
RTIOdrvBRCSerc.reg |
Reg file for above driver |
|
|
RTIOwdmBRCSerc.sys |
Additional Driver for CoDeSys SP RTE under |
|
Windows2000/XP |
|
|
RTIOwdmBRCSerc.inf |
Inf file for above driver |
|
|
tech_doc_e.doc / V1.1
© 3S - Smart Software Solutions GmbH |
Page 3 of 9 |
SercansII_E.doc |
|
SoftMotion: DriveInterface: Bosch Rexroth SercansII PCI
2Job Steps
1.Turn off the PC and take away the voltage.
2.Integrate the PCI card in your PC.
3.Start the PC.
4.(only CoDeSys SP RTE on Windows2000/XP): install RTIOwdmBRCSerc
5.(only CoDeSys SP RTE) copy RTIOdrvBRCSerc.sys into Windows\System32\drivers
6.(only CoDeSys Sp RTE) execute RTIOdrvBRCSerc.reg
7.(only CoDeSys SP RTE) start CoDeSys SP RTE
8.(only CoDeSys SP RTE) add “RTIOdrvBRCSerc” in CoDeSys SP RTE Service-> System-> I/Odrivers
9.start PLC and download application
tech_doc_e.doc / V1.1
© 3S - Smart Software Solutions GmbH |
Page 4 of 9 |
SercansII_E.doc |
|
SoftMotion: DriveInterface: Bosch Rexroth SercansII PCI
3Preconditions and known limitations
-This driver only works with Sercosdrive.lib V1.9.0.2 or later
-This driver only works with CoDeSys SP RTE V2.3.4.4 or later
-This driver has been tested with the SercansII card, hardware version “SCS04-A01”, software version “FWA-SERC*2-SCM-01V01.00-D0”
