Page 1556​

DICOM PS3.3 2020a - Information Object Definitions​

C.32.3.4 Luminance Result Macro​

This Macro records the result of a Luminance QA task for a Display Subsystem.​

Table C.32.3.4-1. Luminance Result Macro Attributes​

Attribute Name​

Tag​

Description​

Number of Luminance Points​

(0028,701B)​ The number of luminance measurements recorded.​

Luminance Response​

(0028,701C)​

Measured Luminance Response Values​

Sequence​



The number of Items shall match the value of Number of Luminance Points​









(0028,701B).​

>DDL Value​

(0028,7017)​

The integer Digital Driving Level (DDL) at which this luminance value was​





measured.​





The DDL Value for the first Item in the Sequence shall be 0. The DDL Value of​





the last Item in the Sequence shall be the maximum DDL value. Two Items in​





the Sequence shall not have the same DDL value. The DDL Value of the Items​





in the Sequence shall increase monotonically.​

>Luminance Value​

(0028,701F)​ Luminance in candelas per square meter (cd/m2) at the measurement location.​





Note​





Each measured luminance includes both ambient light and light from​





the display device.​

>CIExy White Point​

(0028,7018)​

A single measured white point recorded for the display subsystem.​





The white point is recorded as a CIE xy chromaticity with two dimensionless​





floating point values where the first is the x value and the second is the y value.​

Reflected Ambient Light​

(2010,0160)​

Reflected ambient light in candelas per square meter (cd/m2) when the​





measurements were taken.​

Ambient Light Value Source​

(0028,7025)​

Source of the ambient light value.​





Enumerated Values:​

DEFAULT​ a configured default value was used.​

MEASURED​the value was measured at the time of the other measurements.​

PROVIDED​the value was provided by an external source.​

C.33 Content Assessment Modules​

C.33.1 Content Assessment Results Module​

This Module describes the results of the assessment of a SOP Instance.​

The type of observations that are included in the results is up to the implementation. Although all observations with the Observation​ Significance (0082,0008) with value MAJOR are included, inclusion of other observation is on the discretion of the implementation.​

Table C.33.1-1. Content Assessment Results Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Assessment Label​

(0082,0023)​

1​

A label that is used to identify this Assessment.​

Assessment Type Code​

(0082,0021)​

1​

Type of Assessment that was performed.​

Sequence​





Only a single Item shall be included in this Sequence.​







>Include Table 8.8-1 “Code Sequence Macro Attributes”​



BCID 701 “Content Assessment Types”​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 1557​

Attribute Name​

Tag​

Type​



Attribute Description​



Assessment Set ID​

(0082,0016)​

3​

Identifies the set of assessments to which this assessment​







result belongs.​





Assessment Requester​

(0082,0017)​

2​

The person or device that made the assessment request.​

Sequence​





Only a single Item shall be included in this Sequence.​







>IncludeTableC.17-3b“IdentifiedPersonorDeviceMacroAttributes”​





Assessed SOP Instance​

(0082,0004)​

1​

The SOP Instances that were assessed.​



Sequence​





One or more Items shall be included in this Sequence.​







>Include Table 10-11 “SOP Instance Reference Macro Attributes”​







>Referenced Comparison​

(0082,0005)​

1C​

SOP Instance(s) used by the assessor to compare to the​

SOP Instance Sequence​





assessed SOP Instances.​









Required if the assessor used comparison SOP Instances.​







One or more Items shall be included in this Sequence.​

>>Include Table 10-11 “SOP Instance Reference Macro Attributes”​







Assessment Summary​

(0082,0001)​

1​

Summary of the assessment result.​









The relationship between the values of Observation Type​







(0082,0008) found and the Assessment Summary value is​







implementation dependent.​









Enumerated Values:​









PASSED​

The assessment has passed. E.g., no​









observation of major or moderate concern​









was made.​









INCONCLUSIVE​The object(s) have not definitively passed​









or failed. E.g., observations of moderate​









concern were made.​









FAILED​

The object(s) have failed the assessment.​









E.g., observations of major concern were​









made.​



Assessment Summary​

(0082,0003)​

3​

Human-readable summary description of the assessment​

Description​





result.​





Pertinent Resources​

(0038,0101)​

3​

ListofResourcesthatcontaininformationconsideredpertinent​

Sequence​





for the assessment.​









Note​











This may include specifications for the assessment​







process and criteria for determining the Observation​







Type (0082,0008).​









One or more Items may be present in this Sequence.​

>Retrieve URI​

(0040,E010)​

1​

Retrieval access path to resource. Includes fully specified​







scheme, authority, path, and query in accordance with​







[RFC3986].​





>Resource Description​

(0038,0102)​

3​

Description or title of the resource​



Number of Assessment​

(0082,0006)​

1​

Number of Observations made during the assessment.​

Observations​











- Standard -​

Page 1558​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​



Attribute Description​

Assessment Observations​

(0082,0007)​

1C​

Observations made during the assessment.​

Sequence​





RequiredifNumberofAssessmentObservations(0082,0006)​













is not zero.​









Thenumber of Items included in the Sequence shall equalthe​







value of Number of Assessment Observations (0082,0006).​

>Observation Significance​

(0082,0008)​

1​

The significance of this observation regarding the quality or​







effectiveness of the assessed SOP Instance of this​







observation.​









Enumerated Values:​







MAJOR​

The observation represents a major concern.​









Further use of the assessed object(s) is not​









advised.​







MODERATE​ The observation represents a moderate​









concern.Interventionbyanauthorizedperson​









is advised prior to any use of the assessed​









object(s).​







MINOR​

The observation represents a minor concern,​









that does not inhibit further use of the​









assessed object(s).​







CONSISTENT​The observation was consistent with the​









assessment criteria.​

>Observation Basis Code​

(0082,0022)​

1​

Basis on which the Observation was performed.​

Sequence​





Only a single Item shall be included in this Sequence.​







>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

BCID 703 “Basis of Assessment”​

>Observation Description​

(0082,000A)​

1​

Human-readable description of the Observation.​

>Structured Constraint​

(0082,000C)​

2​

Structured Constraint(s) that were used to make this​

Observation Sequence​





observation and description of conformance or violation.​







Zero or more Items shall be included in this Sequence.​

>>Include Table 10.25-1 “Attribute Value Constraint Macro Attributes”​



>>Assessed Attribute Value​

(0082,0010)​

1​

The value of the Attribute in the assessed SOP Instance.​

Sequence​





One or more Items shall be included in this Sequence.​







>>>Include Table 10.26-1 “Attribute Value Macro Attributes”​

C.34 Procedure Protocol Modules​

This section describes Modules specific to the family of Defined and Performed Procedure Protocol IODs.​

C.34.1 CT Protocol Series Module​

The CT Protocol IODs use the General Series Module described in Section C.7.3.1, specialized by the CT Protocol Series Module,​ to describe the DICOM SeriesEntity described in Section A.1.2.3, and to define what constitutes a Series for the context of a Protocol.​

Table C.34.1-1 specifies the Attributes that describe a CT Protocol Series.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​ Page 1559​

Table C.34.1-1. CT Protocol Series Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Modality​

(0008,0060)​

1​

Type of data in this Series.​







Enumerated Values:​







CTPROTOCOL​







See Section C.7.3.1.1.1 for further explanation.​

C.34.2 Protocol Context Module​

The context in which the described Protocol is defined or performed. This Module is applicable to defined and performed procedure​ protocols.​

Details like the Potential Reasons for Procedure Code Sequence (0018,9909) or the Protocol Planning Information (0018,990F) may​ be copied from the defined protocol into the performed protocol to support quality assurance activities like checking whether the​ contents of the Reason for Requested Procedure Code Sequence (0040,100A) recorded in the performed protocol are consistent​ with the contents of the Potential Reasons for Procedure Code Sequence (0018,9909).​

Table C.34.2-1. Protocol Context Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Custodial Organization​

(0040,A07C)​

3​

Custodial organization for this Protocol instance. Represents​

Sequence​





the organization that is currently in charge of maintaining this​







protocol instance.​







Note​







This may or may not be identical to the Institution​







identified in the Equipment Module.This may or may​







not be the Institution that originally created this​







instance.​







Only a single Item is permitted in this Sequence.​

>Institution Name​

(0008,0080)​

2​

Name of Custodial Institution or Organization.​

>Institution Code Sequence​

(0008,0082)​

2​

Coded identifier of Custodial Institution or Organization.​







Zero or one Item shall be included in this Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​

Responsible Group Code​

(0008,0220)​

2​

The department, unit or service that is responsible for the​

Sequence​





management of this Protocol.​







See Section C.34.2.3.​







Zero or more Items shall be included in this Sequence​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

BCID 7030 “Institutional Departments, Units and Services”.​

Protocol Name​

(0018,1030)​

1​

Name for this Protocol.​

Potential Scheduled Protocol​

(0018,9906)​

3​

A list of Protocol Codes for which this Protocol may be​

Code Sequence​





considered a match.​

One or more Items are permitted in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

- Standard -​

Page 1560​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Potential Requested​

(0018,9907)​

3​

A list of Procedure Codes for which this Protocol may be​

Procedure Code Sequence​





considered a match.​







One or more Items are permitted in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​



Potential Reasons for​

(0018,9908)​

3​

List of reasons deemed appropriate by the Protocol author for​

Procedure​





a procedure using this Protocol​







Each reason shall be encoded in a separate value of this​







multi-value Attribute.​







Note​







One of the reasons listed here may be encoded in​







Reason for the Requested Procedure (0040,1002)​







within instances generated from running the Protocol.​

Potential Reasons for​

(0018,9909)​

3​

List of reasons deemed appropriate by the Protocol author for​

Procedure Code Sequence​





a procedure using this Protocol.​







One or more Items are permitted in this Sequence.​







Note​







One of the reasons listed here may be encoded in​







Reason for Requested Procedure Code Sequence​







(0040,100A) within instances generated from running​







the Protocol.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​

Potential Diagnostic Tasks​

(0018,990A)​

3​

List of diagnostic tasks deemed appropriate by the Protocol​







author for a procedure using this Protocol.​







E.g., detect collections of blood, identify brain masses.​

Contraindications Code​

(0018,990B)​

3​

List of reasons for which the authors of the Protocol deemed it​

Sequence​





contraindicated.​







Note​







ConstraintsonvaluesofpatientdemographicAttributes​







such as sex, age or weight are addressed separately​







inthePatientSpecificationModule.SeeSectionC.34.5.​







One or more Items are permitted in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

BCID 1200 “Contraindications For CT Imaging”.​

Predecessor Protocol​

(0018,990E)​

3​

Defined or Performed Procedure Protocol Instances from which​

Sequence​





this Defined Procedure Protocol was derived.​

See Section C.34.2.1.​

This Attribute is not present in Performed Procedure Protocol​ Instances since the Referenced Defined Protocol Sequence​ (0018,990C) is used instead.​

One or more Items are permitted in this Sequence.​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​

- Standard -​

Смотрите также:

«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
Значение, сущность и содержание социально — педагогической деятельности в организации для детей-сирот и детей, оставшихся без попечения родителей
__RGR2
__RGR2
_11_А. Франс для эл версии
_индив анализ данных
- Интерфейс 485 и оптопорт 11
:Конвергентный подход к проектированию дополнительных общеобразовательных общеразвивающих программ
