DICOM PS3.2 2020a - Conformance Page 281
Table G.8.1-5. Hanging Protocol Display Module of Created SOP Instances
Attribute Name |
Tag |
VR |
Value |
Presence of |
Source |
|
|
|
|
Value |
|
Display Sets Sequence |
(0072,0200) |
SQ |
One or more sequence items. |
ALWAYS |
AUTO |
>Display Set Number |
(0072,0202) |
US |
Generated by device. |
ALWAYS |
AUTO |
>Display Set Label |
(0072,0203) |
LO |
From user input |
ANAP |
USER |
>Display Set Presentation |
(0072,0204) |
US |
1 |
ALWAYS |
AUTO |
Group |
|
|
|
|
|
>Image Set Number |
(0072,0032) |
US |
Determined by application. |
ALWAYS |
AUTO |
>Image Boxes Sequence |
(0072,0300) |
SQ |
One sequence item. |
ALWAYS |
AUTO |
>>Image Box Number |
(0072,0302) |
US |
Generated by device. |
ALWAYS |
AUTO |
>>Display Environment |
(0072,0108) |
FD |
DeterminedbyapplicationwithuserALWAYS |
AUTO |
|
Spatial Position |
|
|
input. |
|
|
>>Image Box Layout Type |
(0072,0304) |
CS |
TILED, STACK or SINGLE, |
ALWAYS |
AUTO |
|
|
|
determined by application with user |
|
|
|
|
|
input. |
|
|
>>Image Box Tile Horizontal |
(0072,0306) |
US |
For TILED, determined by |
ANAP |
AUTO |
Dimension |
|
|
application with user input. |
|
|
>>Image Box Tile Vertical |
(0072,0308) |
US |
For TILED, determined by |
ANAP |
AUTO |
Dimension |
|
|
application with user input. |
|
|
>>ImageBoxScrollDirection |
(0072,0310) |
CS |
For TILED, VERTICAL or |
ANAP |
AUTO |
|
|
|
HORIZONTAL, determined by |
|
|
|
|
|
application with user input. |
|
|
>>Image Box Small Scroll |
(0072,0312) |
CS |
For TILED only, value is IMAGE. |
ANAP |
AUTO |
Type |
|
|
|
|
|
>>Image Box Small Scroll |
(0072,0314) |
US |
For TILED only, value is 1. |
ANAP |
AUTO |
Amount |
|
|
|
|
|
>>Image Box Large Scroll |
(0072,0316) |
CS |
For TILED only, value is |
ANAP |
AUTO |
Type |
|
|
ROW_COLUMN. |
|
|
>>Image Box Large Scroll |
(0072,0318) |
US |
For TILED only, value is 1. |
ANAP |
AUTO |
Amount |
|
|
|
|
|
>FilterOperationsSequence |
(0072,0400) |
SQ |
Zero or more sequence items. |
VNAP |
AUTO |
>>Filter-by Category |
(0072,0402) |
CS |
IMAGE_PLANE if present. |
ANAP |
USER/AUTO |
>>Selector Attribute |
(0072,0026) |
AT |
(0008,0008) Image Type, |
ANAP |
USER/AUTO |
|
|
|
(0018,0010) Contrast/Bolus Agent, |
|
|
|
|
|
(0018,0086) Echo Number, |
|
|
|
|
|
(0018,5101) View Position, |
|
|
|
|
|
(0054,0220) View Code Sequence, |
|
|
|
|
|
(0054,0222) View Modifier Code |
|
|
|
|
|
Sequence. |
|
|
>>SelectorSequencePointer |
(0072,0052) |
AT |
Relevant Sequence Attribute TagsANAP |
AUTO |
|
|
|
|
from DICOM Data Dictionary, if |
|
|
|
|
|
Selector Attribute is nested in a |
|
|
|
|
|
Sequence, such as (0054,0220) |
|
|
|
|
|
View Code Sequence. |
|
|
>>Selector Attribute VR |
(0072,0050) |
CS |
VR of Selector Attribute, if presentANAP |
AUTO |
|
>>The attribute from the Hanging Protocol Selector Attribute Value Macro that is required by theANAP |
AUTO |
||||
value of Selector Attribute VR, if present. |
|
|
|
|
|
- Standard -
Page 282 |
DICOM PS3.2 2020a - Conformance |
|
|
||
Attribute Name |
Tag |
VR |
Value |
Presence of |
Source |
|
|
|
|
Value |
|
>>Selector Value Number |
(0072,0028) |
US |
3 for (0008,0008) Image Type, 1 forANAP |
AUTO |
|
|
|
|
other Selector Attributes. |
|
|
>>Filter-by Operator |
(0072,0406) |
CS |
MEMBER_OF or |
ALWAYS |
USER |
|
|
|
NOT_MEMBER_OF. |
|
|
>Sorting Operations |
(0072,0600) |
SQ |
Zero or more sequence items. |
VNAP |
AUTO |
Sequence |
|
|
|
|
|
>>Selector Attribute |
(0072,0026) |
AT |
(0008,0032) Acquisition Time, |
ANAP |
USER |
|
|
|
(0018,0086) Echo Time, |
|
|
|
|
|
(0020,0013) Instance Number. |
|
|
>>SelectorSequencePointer |
(0072,0052) |
AT |
Relevant Sequence Attribute TagsANAP |
AUTO |
|
|
|
|
from DICOM Data Dictionary, if |
|
|
|
|
|
Selector Attribute is nested in a |
|
|
|
|
|
Sequence. |
|
|
>>Selector Value Number |
(0072,0028) |
US |
1 for most Selector Attributes, if |
ANAP |
AUTO |
|
|
|
present. |
|
|
>>Sort-by Category |
(0072,0602) |
CS |
ALONG_AXIS |
ANAP |
USER |
>>Sorting Direction |
(0072,0604) |
CS |
INCREASING or DECREASING |
ALWAYS |
USER |
>Display Set Patient |
(0072,0700) |
CS |
From user input or automated |
ANAP |
USER/AUTO |
Orientation |
|
|
algorithm. |
|
|
>VOI Type |
(0072,0702) |
CS |
From user input or automated |
ANAP |
USER/AUTO |
|
|
|
algorithm. |
|
|
>ShowImageTrueSizeFlag |
(0072,0710) |
CS |
NO |
ALWAYS |
AUTO |
>Show Graphic Annotation |
(0072,0712) |
CS |
YES |
ALWAYS |
AUTO |
Flag |
|
|
|
|
|
>Show Patient |
(0072,0714) |
CS |
YES |
ALWAYS |
AUTO |
Demographics Flag |
|
|
|
|
|
>Show Acquisition |
(0072,0716) |
CS |
YES |
ALWAYS |
AUTO |
Techniques Flag |
|
|
|
|
|
PartialDataDisplayHandling |
(0072,0208) |
CS |
MAINTAIN_LAYOUT |
ALWAYS |
AUTO |
Synchronized Scrolling |
(0072,0210) |
SQ |
Zero or more sequence items, |
ANAP |
USER/AUTO |
Sequence |
|
|
based on user input or automated |
|
|
|
|
|
algorithm. |
|
|
>DisplaySetScrollingGroup |
(0072,0212) |
US |
Display Set numbers. |
ALWAYS |
AUTO |
Navigation Indicator |
(0072,0214) |
SQ |
Zero or more sequence items, |
ANAP |
USER |
Sequence |
|
|
based on user input. |
|
|
>Navigation Display Set |
(0072,0216) |
US |
Display Set number, user or |
ANAP |
USER/AUTO |
|
|
|
automated. |
|
|
>Reference Display Sets |
(0072,0218) |
US |
Display Set numbers, user or |
ALWAYS |
USER/AUTO |
|
|
|
automated. |
|
|
G.8.1.2 Usage of Attributes From Received IODs
No SOP Class specific fields for images are required.
The Reformatting Operation Type (0072,0510) attribute with value MPR or SLAB is supported for the MR Image Storage SOP Class only.
- Standard -
DICOM PS3.2 2020a - Conformance |
Page 283 |
G.8.1.3 Attribute Mapping
Not applicable.
G.8.1.4 Coerced/Modified Fields
No coercion is performed.
G.8.2 Data Dictionary of Private Attributes
No private attributes are defined.
G.8.3 Coded Terminology and Templates
ThevalueforCodeMeaningwillbedisplayedforallcodesequences.Nolocallexiconisprovidedtolookupalternativecodemeanings.
G.8.4 Grayscale Image Consistency
The high resolution display monitor attached to the product can be calibrated according to the Grayscale Standard Display Function (GSDF).
G.8.5 Standard Extended/Specialized/Private SOP Classes
None
G.8.6 Private Transfer Syntaxes
None.
- Standard -
Page 284 |
DICOM PS3.2 2020a - Conformance |
- Standard -
DICOM PS3.2 2020a - Conformance |
Page 285 |
H DICOM Conformance Statement
Medication-System-Gateway (Informative)
Disclaimer:
This document is an example DICOM Conformance Statement for a fictional device called EXAMPLE-MEDICATION-SYSTEM- GATEWAY, which is a networked computer system used to provide radiology systems with access to a pharmacy system and a medication administration record system.
As stated in the annex title, this document is truly informative, and not normative. A conformance statement of an actual product might implement additional services and options as appropriate for its specific purpose. In addition, an actual product might implement the servicesdescribedinadifferentmannerand,forexample,withdifferentcharacteristicsand/orsequencingofactivities.Inotherwords, this conformance statement example does not intend to standardize a particular manner that a product might implement DICOM functionality.
H.0 Cover Page
Company Name: EXAMPLE-GATEWAY-PRODUCTS.
Product Name: EXAMPLE-MEDICATION-SYSTEM-GATEWAY
Version: 1.0-rev. A.1
Internal document number: 4226-xxx-yyy-zzz rev 1
Date: YYYYMMDD
H.1 Conformance Statement Overview
The EXAMPLE-MEDICATION-SYSTEM-GATEWAY is a networked computer system used to provide radiology systems with access to a pharmacy system and a medication administration record system. It allows imaging modalities systems and departmental inform- ation systems to retrieve information about drugs and contrast agents, to verify that administration of a drug or contrast agent to a particular patient is allowed, and to record the administration of a drug or contrast agent to a patient.
Table H.1-1. Network Services
SOP Classes |
User of Service (SCU) |
Provider of Service (SCP) |
Workflow Management |
|
|
Substance Administration Logging |
No |
Yes |
Query/Retrieve |
|
|
Product Characteristics Query |
No |
Yes |
Substance Approval Query |
No |
Yes |
H.2 Table of Contents
A table of contents shall be provided to assist readers in easily finding the needed information.
