Page 256​

DICOM PS3.2 2020a - Conformance​

Application Entity​

Role​

Default AE Title​

Default TCP/IP Port​

STORAGE-SCU​

SCU​

EX_STORE_SCU​

None​

STORAGE-SCP​

SCP​

EX_STORE_SCP​

4000​

QUERY-RETRIEVE-SCP​

SCP​

EX_QUERY_SCP​

5000​

Parameter​

Configurable​

Default Value​

General Parameters​

Maximum PDU size I can receive​

Yes​

128kbytes​

Maximum PDU size I can send​

Yes​

128kbytes​

Time-out waiting for response to TCP/IP connect() request. (Low-level​

Yes​

10 s​

timeout)​

Time-out waiting for A-ASSOCIATE RQ PDU on open TCP/IP connection.​

Yes​

30 s​

(ARTIM timeout)​

Time-out waiting for acceptance or rejection response to an Association​

Yes​

30s​

Open Request. (Application Level timeout)​

Time-out waiting for acceptance of a TCP/IP message over the network.​

Yes​

30 s​

(Low-level timeout)​

Time-out for waiting for data between TCP/IP packets. (Low-level timeout)​

Yes​

30 s​

The Windows NT TCP/IP socket buffer size is set to 1,342,177 bytes in​

No​

1,342,177 bytes​

order to improve image data throughput performance.​

Page 258​

DICOM PS3.2 2020a - Conformance​

Parameter​

Configurable​

Default Value​

QUERY-RETRIEVE-SCPAEmaximumnumberofsimultaneousAssociations​

Yes​

10​

DICOM PS3.2 2020a - Conformance​

Page 259​

Module​

Attribute Name​

Tag ID​

Type​

Significance​

Patient​

Patient Name​

(0010,0010)​

Opt​

STORAGE-SCP AE can be configured to apply a default value if​

there is no value specified.​

Value is saved to database as separate first and last names. Only​

first and last names are entered in the​

EXAMPLE-QUERY-RETRIEVE-SERVERdatabase.Bothfirstand​

last names can be a maximum of 64 characters each.​

Names will be parsed correctly if they are in the format of​

'lname^fname' or 'lname, fname'. If space separation is used (i.e.,​

'lname fname') then the entire name will be treated as the last​

name.​

Patient ID​

(0010,0020)​

Opt​

STORAGE-SCP AE can be configured to apply a default value if​

there is no value specified.​

Verification on incoming Patient IDs is performed. If an ID already​

existsbuttheexistingnamedoesnotmatch,thentheIDiscoerced​

because different Patient records in the​

EXAMPLE-QUERY-RETRIEVE-SERVER database cannot have​

identical Patient IDs.​

Value is saved to database.​

Patient's Birth Date​

(0010,0030)​

Opt​

STORAGE-SCP AE can be configured to apply a default value if​

there is no value specified.​

Value is saved to database.​

Patient's Sex​

(0010,0040)​

Opt​

First character must be 'M', 'm', 'F', 'f', 'O', or 'o'. If a different value,​

or not specified, then will be entered in the database as 'U',​

unknown. Value is saved to database. 'U' is never exported in​

DICOM images; instead, the Element value will be left empty for​

export.​

General​

Study Instance UID​

(0020,000D)​

Mand​

Must be provided.​

Study​

Value is saved to database.​

Study Date​

(0008,0020)​

Opt​

STORAGE-SCP AE can be configured to apply a default value if​

there is no value specified.​

Value is saved to database.​

ReferringPhysician's​

(0008,0090)​

Opt​

Value is saved to database.​

Name​

Page 260​

DICOM PS3.2 2020a - Conformance​

Module​

Attribute Name​

Tag ID​

Type​

Significance​

Accession Number​

(0008,0050)​

Opt​

STORAGE-SCP AE can be configured to apply a default value if​

there is no value specified. Matching used to determine which​

Accession number to apply is configurable (i.e., HIS/RIS provided​

Accession Number may be used if the Patient ID, Patient Name,​

Study Date, and Modality provided in the HIS/RIS and SOP​

Instance match).​

Value is saved to database.​

Study Description​

(0008,1030)​

Opt​

Ifmatchedvalue(s)intheEXAMPLE-QUERY-RETRIEVE-SERVER​

exam type database, then it will be saved to the database as an​

exam type.​

General​

Modality​

(0008,0060)​

Opt​

STORAGE-SCP AE can be configured to apply a default value if​

Series​

there is no value specified.​

Value is saved to database but must be two characters in length.​

Series Description​

(0008,103E)​

Opt​

Ifmatchedvalue(s)intheEXAMPLE-QUERY-RETRIEVE-SERVER​

exam type database then it will be saved to the database as an​

exam type.​

Operator's Name​

(0008,1070)​

Opt​

Value is saved to database.​

Body Part Examined​

(0018,0015)​

Opt​

Ifmatchedvalue(s)intheEXAMPLE-QUERY-RETRIEVE-SERVER​

exam type database then it will be saved to the database as an​

exam type.​

General​

Image Type​

(0008,0008)​

Opt​

If the third value, the modality specific value, matches value(s) in​

Image​

theEXAMPLE-QUERY-RETRIEVE-SERVERexamtypedatabase​

then it will be saved to the database as an exam type.​

Image​

Pixel Spacing​

(0028,0030)​

Opt​

Used for automatic scaling of measurement tool if specified in an​

Plane​

image SOP Instance.​

US Region​Sequence of​

(0018,6011)​

Opt​

Used for automatic scaling of measurement tool if specified in an​

Calibration​Ultrasound Regions​

Ultrasound or Ultrasound Multi-frame Image SOP Instance.​

Image​

Photometric​

(0028,0004)​

Cond​

The following photometric interpretations are supported for image​

Pixel​

Interpretation​

display purposes:​

MONOCHROME1, MONOCHROME2, RGB,​

PALETTE COLOR, YBR FULL 422, and YBR FULL.​

Required if SOP Instance is an Image.​

Bits Allocated​

(0028,0100)​

Cond​

Must be 8 or 16 bits for image display purposes.​

Required if SOP Instance is an Image.​

Bits Stored​

(0028,0101)​

Cond​

Allvaluesof16orfeweraresupportedforimagedisplaypurposes.​

Required if SOP Instance is an Image.​

Overlay​

Overlay Rows​

(6000,0010)​

Cond​

Number of Rows in Overlay.​

Plane​

Required in order to display an Overlay.​

Module​

Overlay Columns​

(6000,0011)​

Cond​

Number of Columns in Overlay.​

(See Note)​
